GrandStream GWN7605LR

GrandStream GWN7605LR 802.11ac Wave 2 Outdoor Access Point :

  • IEEE 802.11a/b/g/n/ac (Wave-2)
  • 1.27Gbps aggregate wireless throughput
  • 2×2:2 2.4GHz (MIMO) + 2×2:2 5GHz (MU-MIMO)
  • 2 × 10/100/1000 Base-T Ports
  • Supports 100+ concurrent Wi-Fi client devices
  • Embedded controller, GWN.Cloud, GWN Manager
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị Wi-Fi Grandstream GWN7605LR Outdoor Access Point

Model GWN7605LR
Wi-Fi Standards  • IEEE 802.11a/b/g/n/ac (Wave-2)
Antennas • 2 dual band external antennas
• 2.4GHz, gain 3.5dBi
• 5 GHz, gain 3.5dBi
Wi-Fi Data Rates • IEEE 802.11ac: 6.5 Mbps to 867 Mbps
• IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• IEEE 802.11n: 6.5Mbps to 300Mbps
• IEEE 802.11b: 1, 2, 5.5, 11Mbps
• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands • 2.4GHz Radio: 2412 – 2484 MHz
• 5 GHz Radio: 5180-5825 MHz
*Not all frequency bands can be used in all regions.
Channel Bandwidth  • 2.4G: 20 and 40MHz
• 5G: 20, 40 and 80 MHz
System Security • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
MIMO  • 2×2:2 2.4GHz (MIMO)
• 2×2:2 5GHz (MU-MIMO))
Coverage Range • Up to 250 meters
*Coverage range can vary based on environment
Maximum TX Power • 2.4G: 24 dBm
• 5G: 22dBm
*Maximum power varies by country, frequency band, and MCS rate
Receiver Sensitivity 2.4G
  802.11b: -96dBm@1Mbps, -88dBm@11Mbps
  802.11g: -93dBm @6Mbps, -75dBm@54Mbps
  802.11n 20MHz: -73dBm @MCS7
  802.11n 40MHz:-70dBm @MCS7
5G
  802.11a: -92dBm @6Mbps, -74dBm @54Mbps
  802.11ac 20MHz: -67dBm@MCS8
  802.11ac: HT40: -63dBm @MCS9
  802.11ac 80MHz: -59dBm @MCS9
SSIDs  • 16 SSIDs total, 8 per radio (2.4 Ghz and 5 Ghz)
Concurrent Clients  • 100+
Network Interfaces  • 2 × autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports  • 1 × Reset Pinhole
Mounting  • Outdoor metal bar mount or wall mount, kits included
LEDs  • 1× tri-color LEDs for device tracking and status indication
Network Protocols  • IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS  • 802.11e/WMM, VLAN, TOS
Network Management • Embedded controller can manage up to 50 local GWN APs
• GWN Cloud offers a free cloud management platform for unlimited GWN APs
• GWN Manager (BETA) offers premise-based software controller for up to 3,000 GWN APs
Power and Green Energy Efficiency  • PoE 802.3af/ 802.3at; Maximum Power Consumption: 10.16W
Environmental • Operation: -30°C to 70°C
• Storage: -30°C to 80°C
• Humidity: 5% to 95% Non-condensing
Physical  • Unit Dimension: 358.3mm(L) x 115mm(W) x 45.3mm(H)
• Unit Weight: 500g
• Entire Package Dimension: 258 × 247× 86mm
• Entire Package Weight:655.3g
Package Content  • GWN7605LR 802.11ac Wave-2 Wireless AP, Mounting Kits, Quick Start Guide
Weatherproof Grade  • IP66-level weatherproof capability when installed vertically
Compliance  • FCC, CE, RCM, IC
