MX75-HW - Cisco Meraki MX75 Security and SD-WAN Appliance

Meraki MX75-HW

MX75-HW Cisco Meraki MX75 Security and SD-WAN Appliance ● Interfaces - WAN: 1x GbE SFP, 2x GbE RJ45, 1x USB (cellular failover); LAN: 10x GbE RJ45 (2x PoE) ● Firewall Throughput: 1 Gbps ● VPN Throughput: 500Mbps ● Recommended users: 200 ● License Options

Giá bán : Liên hệ để có giá tốt

Tình trạng : Còn hàng

Network and Security Services
- Stateful firewall, 1:1 NAT, DHCP, DMZ, static routing
- Identity-based policies
- Auto VPN™ self-configuring site-to-site VPN
- Client VPN (IPsec)
- User and device quarantine
- VLAN support and DHCP services
Advanced Security Services
- Content filtering (Webroot BrightCloud CIPA-compliant URL database)
- Web search filtering (including Google and Bing SafeSearch)
- YouTube for Schools
- Intrusion prevention (SourceFire Snort based)
- Cisco Advanced Malware Protection (AMP)
- Requires Advanced Security License
WAN Performance Management
- WAN link aggregation
- Application level (Layer 7) traffic analysis and shaping
- Automatic Layer 3 failover (including VPN connections)
- WAN uplink selection based on traffic type

Monitoring and Management
- Web based management and configuration
- Throughput, connectivity monitoring and alerts
- Network asset discovery and user identification
- Built-in network-wide reporting, monitoring and alerts
- Centralized policy management
- Real-time diagnostic and troubleshooting over the web
- Automatic firmware upgrades and security patches
- Searchable network-wide event logs
Interfaces
- WAN: 1 x GbE SFP, 2 x GbE RJ45
- LAN: 10 × GbE RJ45 (2 x x PoE)
- USB: 1 × USB 2.0 for 3G/4G failover
Performance
- Stateful firewall throughput: 1 Gbps
- VPN throughput: 500 Mbps
- Recommended for small branches (up to 200 users)
Power
- Single 100W power supply
Environment
- Operating temperature: 32°F to 113°F (0°C to 45°C)
- Humidity: 5 to 95% non-condensing
Warranty
- Lifetime hardware warranty with advanced replacement included

Meraki Model	MX75
Recommended Use Cases	Small branch with up to 200 users
Stateful Firewall Throughput	1 Gbps
Advanced Security Throughput	750 Mbps
Maximum site-to-site VPN Throughput	500 Mbps
Maximum site-to-site VPN Tunnels	75
WAN Interfaces (Dedicated) Dual-purpose	1x GbE SFP 2x GbE RJ45 (cellular failover)
LAN Interfaces (fixed)	10x GbE RJ45 (2x PoE)
Mounting	Desktop or Wall mount
Dimensions (W x D x H)	11.14” x 5.83” x 1.06” (283 mm x 148 mm x 27 mm)
Weight	1.87 lb (0.85 kg)
Power Supply	100W DC (included)
Power Load (idle/max)	12W / 96W
Operating Temperature	32°F to 113°F (0°C to 45°C)
Humidity	5% to 95%

License	Description
Enterprise License and Support
LIC-MX75-ENT-1YR	Cisco Meraki MX75, 1-year Enterprise License and Support
LIC-MX75-ENT-3YR	Cisco Meraki MX75, 3-year Enterprise License and Support
LIC-MX75-ENT-5YR	Cisco Meraki MX75, 5-year Enterprise License and Support
Advanced Security License and Support
LIC-MX75-SEC-1YR	Cisco Meraki MX75, 1-year Advanced Security License and Support
LIC-MX75-SEC-3YR	Cisco Meraki MX75, 3-year Advanced Security License and Support
LIC-MX75-SEC-5YR	Cisco Meraki MX75, 5-year Advanced Security License and Support
Secure SD-WAN Plus License and Support
LIC-MX75-SDW-1YR	Cisco Meraki MX75, 1-year Secure SD-WAN Plus License and Support
LIC-MX75-SDW-3YR	Cisco Meraki MX75, 3-year Secure SD-WAN Plus License and Support
LIC-MX75-SDW-5YR	Cisco Meraki MX75, 5-year Secure SD-WAN Plus License and Support

Package Contents	Models (s)
Mounting kit	MX64, MX64W, MX67, MX67W, MX67C, MX68, MX68W, MX68CW, MX84, MX100, MX250, MX450
Cat 5 Ethernet cable (2)	MX64, MX64W, MX67, MX67W, MX67C, MX68, MX68W, MX68CW, MX84, MX100, MX250, MX450
AC power adapter	MX64, MX64W, MX67, MX67W, MX67C, MX68, MX68W, MX68CW, MX85
Wireless external omni antenna (2)	MX64W, MX67W, MX68W
150W power supply	MX105
250W power supply (2)	MX250, MX450
System fan (2)	MX105, MX250, MX450
SIM card ejector tool	MX67C, MX68CW
Fixed external wireless and LTE paddle antennas	MX68CW
Removable external LTE paddle antennas	MX67C

Model	Description
MA-SFP-1GB-SX	Cisco Meraki 1 GbE SFP SX Fiber Module (1000BASE-SX, range: 550m) for MX75, MX85, MX95, MX105, MX84, MX100, MX250, MX450
MA-SFP-1GB-TX	Cisco Meraki 1 GbE RJ45 Copper Module (1000BASE-T for twisted pair) for MX75, MX85, MX95, MX105, MX84, MX100, MX250, MX450
MA-SFP-10GB-SR	Cisco Meraki 10 GbE Short Range SFP+ Module (10GBASE-SR, range: 400m) for MX95, MX105, MX250, MX450
MA-CBL-TA-1M	Cisco Meraki 10 GbE Twinax Cable with SFP+ Connectors (10GSFP+Cu, range: 1m) for MX95, MX105, MX250, MX450
MA-CBL-TA-3M	Cisco Meraki 10 GbE Twinax Cable with SFP+ Connectors (10GSFP+Cu, range: 3m) for MX95, MX105, MX250, MX450
MA-PWR-30WAC	Replacement Power Adapter (30W) for MX64, MX64W, MX67, MX67W, MX67C
MA-PWR-100WAC	Replacement Power Adapter (100W) for MX68, MX68W, MX68CW
MA-PWR-150WAC	Meraki MX105 Power Supply Unit (PSU)
MA-PWR-250WAC	Meraki MX250/MX450 Power Supply Unit (PSU)
MA-FAN-18K	Meraki 18K RPM System Fan for MX105, MX250 and MX450
MA-ANT-MX	One pair of external dual-band dipole antennas (connector type: RP-SMA) for MX64W, MX67W, or MX68W
