Aruba AP-303P (R0G68A)

R0G68A - Aruba AP-303P (RW) Dual 2x2:2 MU-MIMO Radio Internal Antennas Unified Campus AP Dual Ethernet.
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị phát sóng Wifi Indoor Aruba AP-303P (R0G68A)

Model AP-303P (R0G68A)
Wi-Fi Radio Specifications
  • AP type: Indoor, dual radio, 5GHz 802.11ac 2x2 MIMO and 2.4GHz 802.11n 2x2 MIMO
  • 5GHz (radio 0):
    • Two spatial stream Single User (SU) MIMO for up to 867 Mbps wireless data rate to individual 2SS VHT80 client devices
    • Two spatial stream Multi User (MU) MIMO for up to 867 Mbps wireless data rate to two 1SS MU-MIMO capable client devices simultaneously
  • 2.4GHz (radio 1):
    • Two spatial stream Single User (SU) MIMO for up to 300 Mbps wireless data rate to individual 2SS HT40 client devices
  • Support for up to 256 associated client devices per radio, and up to 16 BSSIDs per radio
Wi-Fi Antennas
  • Two vertically polarized dual-band downtilt omnidirectional antennas for 2x2 MIMO with peak antenna gain of:
    • 3.4dBi in 2.4GHz and 7.8dBi in 5GHz for AP-303P
  • The antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
  • Combining the patterns of both antennas per radio, the peak gain of the average (effective) pattern is:
    • 2.1dBi in 2.4GHz and 5.9dBi in 5GHz for AP-303P
Other Interfaces
  • E0: One 10/100/1000BASE-T Ethernet network interface (RJ-45)
    • Auto-sensing link speed and MDI/MDX
    • 802.3az Energy Efficient Ethernet (EEE)
    • PoE-PD: 48Vdc (nominal) 802.3af/at/bt PoE
  • E1 (AP-303P models only): One 10/100/1000BASE-T Ethernet network interface (RJ-45)
    • Auto-sensing link speed and MDI/MDX
    • 802.3az Energy Efficient Ethernet (EEE)
    • PoE-PSE (output): 48Vdc (nominal) 802.3af/at PoE
  • DC power interface
  • Bluetooth Low Energy (BLE) radio
  • Zigbee 802.15.4 radio (AP-303P models only)
  • Visual indicators (tri-color LEDs): for System and Radio status
  • Reset button: factory reset (during device power-up), LED mode control (normal/off)
  • Serial console interface (proprietary, µUSB physical jack)
  • Kensington security slot
Power Sources and Consumption
  • The AP supports direct DC power and Power over Ethernet (PoE)
  • When both power sources are available, DC power takes priority over PoE
  • Direct DC source: 48Vdc nominal, +/- 5%
  • DC power interface accepts 1.35/3.5-mm center-positive circular plug with 9.5-mm length
  • Power over Ethernet (PoE-PD) on E0: 48Vdc (nominal) 802.3af/at/bt compliant source
  • PoE-PSE function on E1 disabled when powered by 802.3af PoE, limited to class 3 when powered by 802.3at PoE, unrestricted when powered by 802.3bt PoE or DC
  • Maximum (worst-case) power consumption: 11.3 W (PoE) or 11.5 W (DC)
  • Maximum (worst-case) power consumption in idle mode: 6.8 W (PoE) or 7.0 W (DC)
  • Power consumption numbers exclude power to support PoE-PSE function on E1
Mechanical
  • Dimensions and weight (unit, excluding mount accessories):
    • 150mm (W) x 150mm (D) x 35mm (H) or 5.9” (W) x 5.9” (D) x 1.4” (H)
    • AP-303P models: 280g or 9.9oz
  • Dimensions and weight (shipping):
    • 190mm (W) x 180mm (D) x 60mm (H) or 7.4” (W) x 7.0” (D) x 2.4” (H)
    • AP-303P models: 430g or 15.2oz
Environmental
  • Operating:
    • Temperature: 0° C to +40° C (+32° F to +104° F)
    • Humidity: 5% to 93% non-condensing
  • Storage and transportation:
    • Temperature: -40° C to +70° C (-40° F to +158° F)

R0G68A : Aruba AP-303P (RW) Dual 2x2:2 MU-MIMO Radio Internal Antennas Unified Campus AP Dual Ethernet.

Data sheet Aruba 303 Series Wireless Access Points
