ASUSTOR AS6510T

ASUSTOR LOCKERSTOR 10 (AS6510T): 10-bay Tower (up to 18-bay), Quad Core 2.1 GHz , 8GB RAM (up to 32GB)

  • Storage: 10 x 3.5" SATA HDD or 2.5" SATA HDD/SSD + 2 x M.2 Drive Slots
  • CPU: Intel ATOM C3538 Quad-Core 2.1GHz, x64 64-bit
  • Memory: 8GB (1 x 8GB) SO-DIMM DDR4 (Max. 64GB)
  • Expansion:  2x USB 3.2 Gen 1
  • Network: 2 x 10GbE (10G/1G); 2 x 2.5GbE (2.5G/1G/100M)
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị lưu trữ NAS ASUSTOR LOCKERSTOR 10 (AS6510T)

Product (SKU) LOCKERSTOR 10 (AS6510T)
CPU
CPU Model Intel ATOM C3538
CPU Architecture x64 64-bit
CPU Frequency Quad Core 2.1GHz
Memory
Memory 8GB SO-DIMM DDR4
Memory Module Pre-installed 8GB (1 x 8GB)
Total Memory Slots 2
Memory Expandable up to 64GB (2 x 32GB) (Support mixed capacity)
Flash Memory 4GB eMMC
Storage
Drive Bays 10
M.2 Drive Slots 2
Compatible Drive Type
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe
  • M.2 2280 SATA 3
  • M.2 2260 SATA 3
  • M.2 2242 SATA 3
Maximum Drive Bays with Expansion Unit 18
External Ports
Expansion 2 x USB 3.2 Gen 1
Network 2 x 10 Gigabit Ethernet(10G/1G);
2 x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Others
System Fan 2 x 120mm
LCD Panel
Power Supply Unit / Adapter 250W x1
Input Power Voltage 100V to 240V AC
Certification FCC, CE, VCCI, BSMI, C-TICK
Warranty 3 Years
Operation
Power Consumption 76.8 W (Operation)
41.1 W (Disk Hibernation)
Noise Level 22dB (HDD idle)
Operation Temperature 0°C~40°C (32°F~104°F)
Humidity 5% to 95% RH
Size and Weight
Size 215.5(H) x 293(W) x 230(D) mm
Weight 6.4 (kg) / 14.1 (lb)

Data sheet ASUSTOR LOCKERSTOR 10 (AS6510T)


10-bay Tower (up to 18-bay), Quad Core 2.1 GHz , 8GB RAM (up to 32GB)
 - CPU: Intel ATOM C3538 Quad-Core 2.1GHz, x64 64-bit
 - Memory: 8GB (1 x 8GB) DDR4 SODIMM (Max.64GB)
 - Total Memory Slots: 2
 - Flash memory: 4GB eMMC
 - Storage: 10 x 3.5" SATA HDD or 2.5" SATA HDD or 2.5" SATA SSD
 - M.2 Drive Slots: 2 x M.2 PCIe (NVMe) / M.2 SATA (2280, 2260,2242)
 - Max Internal Capacity: 180TB (18TB HDD X 10, Capacity may vary by RAID types)
 - Maximum Capacity with Expansion Units: 324TB (18TB HDD X 18, Capacity may vary by RAID types)
 - External Ports: USB 3.2 Gen 1 x 2
 - LAN: 10 Gigabit Ethernet (10G/1G) x 2 + 2.5 Gigabit Ethernet (2.5G/1G/100M) x 2
 - Maximum IP cam: 64 ( 4 free license included)
 - Power Supply Unit / Adapter: Single 250W
 - Expansion unit: AS6004U - 4 bay
 - Toolless installation.
