5PX3000IRT2UG2 - Eaton 5PX Gen2 UPS :
Bộ lưu điện UPS Eaton 5PX Gen2 5PX3000IRT2UG2
| Model | 5PX3000IRT2UG2 |
| Rating (VA/W) | • 3000VA / 3000W |
| Format | • RT2U |
| Electrical Characteristics | |
| Technology | • Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
| Input voltage range without using batteries | • 160V-294V (adjustable to 150V-294V) |
| Input frequency range without using batteries | • 47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode |
| Output voltage | • 230 V (+6/-10 %) (Adjustable to 200V* / 208V / 220V / 230V / 240V), 50/60 Hz +/- 0.1 Hz (autosensing) |
| Connections | |
| Input | • IEC C20 (16A) |
| Outputs | • 8 x IEC C13 (10A) • 2 x IEC C19 (16A) |
| Remote controlled sockets | • 1 group of 2 x IEC C13 (10 A) • 1 group of 2 x IEC C13 (10 A) + 1 x IEC C19 (16A) |
| Additional outputs with HS MBP | • 4 FR / Schuko sockets or 3 BS sockets or 6 IEC 10A sockets or terminal blocks (HW version) |
| Additional outputs with FlexPDU | • 8 FR / Schuko sockets or 6 BS sockets or 12 IEC 10A sockets |
| Interfaces | |
| Communication ports | • 1 USB port + 1 serial RS232 port + 1 mini-terminal block for Remote ON/OFF + 1 mini-terminal block for Remote Power OFF + 1 mini-terminal block for output relay |
| Communication slot | • 1 slot for Network M2 (included in Netpack version), INDGW-M2 or Relay-MS cards |
| Operating conditions, standards and approvals | |
| Operating temperature | • 0 to 40°C |
| Noise level | • <40 dB @ typical load |
| Safety | • IEC/EN 62040-1, UL1778, CSA22.2 |
| EMC, Performance | • IEC/EN 62040-2, FCC Class B, CISPR22 class B |
| Approvals | • CE / CB report (TUV) / cTUVus / EAC / UKCA / Ukr / Cm |
| Dimensions W x D x H / Weight | |
| UPS Dimensions (mm) | • 438 x 603 x 85.5 |
| UPS Weight (kg) | • 31.7 |
| EBM dimensions (mm) | • 438 x 603 x 85.5 |
| EBM weight (kg) | • 40.4 |
