CPAP-SG1575R-SNBT-AC - Thiết bị tường lửa Firewall Check Point SG1575R Quantum Rugged dành cho môi trường công nghiệp
Check Point 1575R Quantum Rugged là tường lửa thế hệ tiếp theo (NGFW) giúp bảo vệ các khu công nghiệp, nhà máy sản xuất được kết nối an toàn. Với thiết kế chắc chắn của Quantum Rugged và khả năng hoạt động ở nhiệt độ từ -40°C đến 75°C, lý tưởng cho các môi trường như nhà máy sản xuất và điện ứng dụng công nghiệp, cơ sở dầu khí, đội tàu hàng hải, hệ thống quản lý tòa nhà,... Kết nối các thiết bị với 1575R qua cổng Serial RS232/RS422/R485, có dây hoặc Wi-Fi, sau đó kết nối 1575R với mạng quản lý OT thông qua cáp đồng hoặc cáp quang 1 GbE hoặc tùy chọn SIM LTE. 1575R được chứng nhận các thông số kỹ thuật công nghiệp IEEE 1613 và IEC 61850-3 về nhiệt, độ rung và khả năng chống nhiễu điện từ (EMI). Ngoài ra, 1575R còn được chứng nhận hoạt động hàng hải theo tiêu chuẩn IEC-60945 và IACS E10 cũng như tuân thủ DNV-GL-CG-0339.
Đặc điểm nổi bật của Check Point 1575R Quantum Rugged
Thông số kỹ thuật
Model | 1575R (CPAP-SG1575R-SNBT-AC) |
Enterprise Testing Conditions | |
Threat Prevention (Mbps) | 400 |
Next Generation Firewall (Mbps) | 830 |
IPS Throughput (Mbps) | 1000 |
Firewall Throughput (Mbps) | 1970 |
RFC 3511, 2544, 2647, 1242 Performance (LAB) | |
Firewall 1518 Byte UDP Packets (Mbps) | 4,000 |
VPN AES-128 Throughput (Mbps) | 1,100 |
Connections per Second | 14600 |
Concurrent Connections | 1,000,000 |
Software | |
Security | Firewall, VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot, Antivirus and SandBlast Threat Emulation (sandboxing) |
Unicast, Multicast Routing and Clustering | OSPFv2, BGPv4 and 4++, RIP, PIM (SM, DM, SSM), IGMP, ClusterXL High Availability |
IPv6 | Local network and internet connections, dual stack tunneling IPv4 over IPv6 networks, prefix delegation |
Mobile Access License (Users) | 200 remote SNX or Mobile VPN client users |
Protocols | Over 70 protocols, including the most popular in the industry: Modbus, Bacnet, CIP, S7, IEC-104, DNP3 and many more |
Hardware | |
WAN Port | 1 x 10/100/1000Base-T RJ-45 / 1 x 1000BaseF SFP port (transceiver not included) |
DMZ Port | 1 x 10/100/1000Base-T RJ-45 / 1 x 1000BaseF SFP port (transceiver not included) |
LAN Ports | 8 x 10/100/1000Base-T RJ-45 ports |
Console Port | 1 x USB-C |
USB Port | 1 x USB 3.0 |
SD Card Slot | Micro-SD slot |
Bypass NIC | No |
Serial Port | 1 x DB9 female connector, supports RS232 serial protocols, (RS422, R485 ready) |
Dimensions | |
Enclosure | Desktop, wall mount, DIN rail (bottom and back mount options) |
Dimensions (W x D x H) | 150 x 150 x 90 mm, 5.9 x 5.9 x 3.5 in. |
Weight | 1.8 kg (3.0 lbs.) |
Environment | |
Operating | -40ºC ~ 75ºC (-40ºF ~ +167ºF) |
Storage | -45ºC ~ 85ºC, (-49ºF ~ 185ºF), 5~95%, non-condensing |
Power Requirements | |
Power Redundancy | Supported |
Power Adapter AC Input | 110 – 240VAC, 50 – 60 Hz, AC socket IEC 320-C14 Type |
Power Adapter Options | 12V/10A 120W industrial grade (-40º ~ 70ºC, -40º ~ 158ºF) power adapter Note: power adapter sold separately |
DC Input (3-pin terminal) | Nominal 12 to 60VDC, -48VDC, Maximum Range 10.2VDC to 72VDC |
Power Consumption (Max) | Wired: 25.1W, Wi-Fi-LTE: 30.7W |
Heat Dissipation | Wired: 85.6 BTU/hr., Wi-Fi-LTE: 104.8 BTU/hr. |
MTBF | |
DC Input (@ 25ºC) | 268.8 years |
AC Input, Industrial grade (@ 25ºC) | 30.2 years |
Certifications | |
Safety | CB IEC, UL, CE LVD - IEC 62368-1, UL/c 62368-1, CE LVD EN62368-1, ASNZ 62368-1 |
EMC (Emissions) | CE, UKCA, FCC, IC , VCCI, AS_NZS ACMA |
Environment | RoHS, REACH, WEEE, POP, TSCA |
Industrial Certifications | IEEE 1613, IEC 61850-3, IEC 60945, EN/IEC 60529 |
Rugged Certifications | EN/IEC 60529, IEC 60068-2-27 shock, IEC 60068-2-6 vibration |
Maritime | IEC-60945 B, DNV-GL-CG-0339 |
IP Rating | IP30 |
Cellular | PTCRB, GCF and Carriers AT&T and Verizon certified |
