Cisco C9200L-48PXG-2Y-A Catalyst 9200L 48-port 8xmGig, 40x1G, 2x25G, PoE+(740W), Network Advantage
| Switch Model | C9200L-48PXG-2Y-A |
| Downlinks total 10/100/1000 or PoE+ copper ports | 48 ports full POE+ (8 mGig ports up to 10G, 40 ports up to 1G) |
| Uplink configuration | 2x 1/10/25G fixed uplinks |
| Default primary AC power supply | 1000W AC (PWR-C5-1KWAC) |
| Available PoE power | 740W |
| Fans | Fixed redundant |
| Software | Network Advantage |
| Stacking support | StackWise®-80 |
| Stacking bandwidth | 80 Gbps |
| Total number of MAC addresses | 16,000 |
| Total number of IPv4 routes | 11,000 |
| IPv4 routing entries | 3,000 |
| IPv6 routing entries | 1,500 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,500 |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 4096 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo frames | 9198 bytes |
| Switching capacity | 340 Gbps |
| Forwarding rate | 252.97 Mpps |
| Chassis Dimensions | 4.4 x 44.5 x 35.0 cm |
| Weight | 5.71 Kg |
| Stacking cables cho Cisco Catalyst C9200L | |
| Product number | Product description |
| C9200L-STACK-KIT | Stack kit for C9200L SKUs only: Two data stack adapters and one data stack cable |
| STACK-T4-50CM | 50CM Type 3 Stacking Cable |
| STACK-T4-1M | 1M Type 3 Stacking Cable |
| STACK-T4-3M | 3M Type 3 Stacking Cable |
| DNA licenses cho Cisco Catalyst C9200L | |
| Product number | Product description |
| C9200L-DNA-E-48-3, -5, -7 | C9200L 48 port Cisco DNA Essentials; 3, 5 and 7 year term |
| C9200L-DNA-A-48-3, -5, -7 | C9200L 48 port Cisco DNA Advantage; 3, 5 and 7 year term |
| C9200L-DNA-P-48-3, -5, -7 | C9200L 48 port Cisco DNA Premier; 3, 5 and 7 year term |
| C9200-DNA-E-A-3, -5, -7 | C9200 Cisco DNA Essentials to Advantage upgrade; 3, 5 and 7 year term |
C9200L-48PXG-2Y-A : C9200L 48-port 8xmGig, 40x1G, 2x25G PoE+, Network Advantage
