Mô tả sản phẩm

Thiết bị chuyển mạch Switch Cisco Industrial IE-9320-16P8U4X-A

Model	IE-9320-16P8U4X-A
Hardware configurations
Downlinks	• 16 ports 10/100/1000M PoE+ and 8 ports 100/1000/2500M 4PPoE (up to 90W/port)
Uplinks (SFP/SFP+)	• 4 ports 1/10G
Software license (default)	• Network Advantage
Hardware	• 4-GB DRAM • 8-GB onboard flash memory
Removable storage	• USB, SD card
Alarms	• 4 dry-contact alarm inputs • 1 dry-contact Form-C relay alarm output
Console ports	• 1 RS-232 (via RJ-45), 1 Micro USB
Power inputs	• Dual AC/DC power inputs
Cisco StackWise® ports	• 2 stacking ports
Performance and scalability features
Forwarding rate	• 76 Gbps (line rate/nonblocking)
Switching bandwidth	• 152 Gbps (switching bandwidth is full-duplex capacity)
Number of queues / port	• 8 egress
Unicast MAC addresses	• 16000
Internet Group Management Protocol (IGMP) multicast groups	• 1000
VLANs	• 1024
IPv4 indirect routes	• 4000
IPv6 indirect routes	• 2000
Spanning Tree Protocol (STP) instances	• 128
Access Control List (ACL) entries (port ACL [PACL], VLAN ACL [VACL], router ACL [RACL])	• 1408
DRAM	• 4 GB
Flash (user accessible)	• 2.5 GB
SD card capacity	• 4 GB
SD Access Fabric Edge Support	• Yes (32 VNs)
SGT/DGT policies	• 2000
IPv4 to SGT binding	• 10000
Maximum SVIs	• 984
SXP Sessions	• 200
Physical configurations
Dimensions (H x W x D)	• 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H • 1.72 x 17.5 x 15.18 in. with PWR-RGD-AC-DC-250 • 1.72 x 17.5 x 15.57 in. with PWR-RGD-AC-DC-400
Weight	• 4.5 kg
Mounting	• Rack mount
Power consumption	• 45W
