Thiết bị mạng Switch Cisco Nexus N9K-C93240YC-FX2
| Mã sản phẩm | N9K-C93240YC-FX2 |
| Characteristics | |
| Ports | 48 x 1/10/25-Gbps and 12 x 40/100- Gbps QSFP28 ports |
| Supported speeds | 1/10/25-Gbps on downlinks 40/100-Gbps on uplinks |
| CPU | 4 cores |
| System memory | Upto 24 GB |
| SSD drive | 128 GB |
| System buffer | 40 MB |
| Management ports | 2 ports: 1 RJ-45 and 1 SFP+ |
| USB ports | 1 |
| RS-232 serial ports | 1 |
| Power supplies (up to 2) | 750W AC*, 1100W AC, 1100W DC, 1100W HVAC/HVDC |
| Typical power (AC) | 298W |
| Maximum power (AC) | 708W |
| Input voltage (AC) | 100 to 240V |
| Input voltage (High-Voltage AC [HVAC]) | 100 to 277V |
| Input voltage (DC) | –40 to –72V |
| Input voltage (High-Voltage DC [HVDC]) | –240 to –380V |
| Frequency (AC) | 50 to 60 Hz |
| Fans | 5 |
| Airflow | Port-side intake and exhaust |
| Physical dimensions (H x W x D) | 2.1 x 17.3 x 23.3 in. (5.3 x 43.9 x 59.1 cm) |
| Acoustics | 76.4 dBA at 50% fan speed, 83.3 dBA at 70% fan speed, and 92.1 dBA at 100% fan speed |
| RoHS compliance | Yes |
| MTBF | 365,610 hours |
| Minimum ACI image | ACI-N9KDK9-14.0 |
| Minimum NX-OS image | NXOS-703I7.3 |
| Hardware performance and scalability specifications | |
| Maximum number of Longest Prefix Match (LPM) routes | 896,000 |
| Maximum number of IP host entries | 896,000 |
| Maximum number of MAC address entries | 256,000 |
| Maximum number of multicast routes | 128,000 |
| Number of Interior Gateway Management Protocol (IGMP) snooping groups | Shipping: 8,000 Maximum: 32,000 |
| Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch | 16 |
| Maximum number of Access Control List (ACL) entries | Per slice of the forwarding engine: 5000 ingress 2000 egress |
| Maximum number of VLANs | 4096 |
| Number of Virtual Routing and Forwarding (VRF) instances | Shipping: 1,000 Maximum: 16,000 |
| Maximum number of ECMP paths | 64 |
| Maximum number of port channels | 512 |
| Maximum number of links in a port channel | 32 |
| Number of active SPAN sessions | 4 |
| Maximum number of VLAN’s in Rapid per-VLAN Spanning Tree (RPVST) instances | 3,967 |
| Maximum number of Hot-Standby Router Protocol (HSRP) groups | 490 |
| Number of Network Address Translation (NAT) entries | 1,023 |
| Maximum number of Multiple Spanning Tree (MST) instances | 64 |
| Flow-table size used for Cisco Tetration Analytics platform | 64,000 |
| Number of Queues | 8 |
| Environmental properties | |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Nonoperating (storage) temperature | –40 to 158°F (–40 to 70°C) |
| Humidity | 5 to 95% (noncondensing) |
| Altitude | 0 to 13,123 ft (0 to 4000m) |
| Weight | |
| Weight without power supplies or fans | 2.2 lb (10 kg) |
N9K-C93240YC-FX2 - Nexus 9K Fixed with 48p 1/10G/25G SFP and 12p 40G/100G QSFP28
