Đầu nối RJ45-Modular Jack LS UTP CAT6 không chống nhiễu, dạng ERI, có mặt che bụi (LS-MJ-UC6-xx-ERD) - Category 6 Unshielded Keystone Jack, ERI type with door
Đầu nối RJ45-Modular Jack LS UTP CAT6 Unshielded ERD (LS-MJ-UC6-xx-ERD)
Part Number: LS-MJ-UC6-xx-ERD (xx: WH, BK, BL)
Category 6 Unshielded Keystone Jack, Enhanced RIDC type with door.
Description
- LS Simple™ Category 6 modular jacks are designed and manufactured to meet today’s and tommorow’s demanding international standards.
- It takes into consideration the need for reliable and quick installations.
- The jack is individually terminated using Insulation Displacement Connectors (IDC) giving assurance of wire connection when using a punch down tool and tool-less for installation.
- User instructons and basic wiring layout for standard configuration are included.
- The LS Simple™ modular jack comes with the ability to wire to a T568A or T568B configuration and fully complies with ANSI / TIA-568-C.2 Category 6.
- Electrical performances comply with ANSI/TIA-568-C.2 (Category 6 performance levels).
- Architectural design and flexibility – Support max. 4 connection channels.
- Universal design and label supports both T568A and T568B wiring.
- IDC Connector accept and allow quick, easy installation of 23~26AWG cable.
- Optimal performance is achieved when using SimpleTM Category 6 patch cords.
- Qualifies for the LS 25-Year Extended Product Warranty and Applications Assurance when included as part of a registered LS Category 6 Channel.
- Dimension: 0.76 x 0.66 x 1.5 inch.
Application
- Horizontal Distribution & Backbone Cabling.
- 4/16 Mbps Token Ring (IEEE 802.5).
- 10/100/1000 BASE-T (IEEE 802.3).
- 155Mbps ATM.
- 100Mbps TP-PMD.
- ISDN, ADSL.
- ATM LAN 1.2G.
Approvals
- Category - ANSI/TIA-568-C.2 Category 6, ISO / IEC 11801 Class E.
- Meet - FCC CFR 47 Parts 68.
- Wiring Scheme - T568A / T568B.
Sản xuất tại Đài Loan
| LS-MJ-UC6-xx-ERD | Đầu nối cáp UTP CAT6 không chống nhiễu, dạng ERI, có mặt che bụi Category 6 Unshielded Keystone Jack, ERI type with door |
