Standards
- IEEE 802.11b/g/n on 2.4 GHz
- IEEE 802.11a/n/ac on 5 GHz
Processor
- Qualcomm® 717 MHz Quad-Core CPU
- 4x ARM Cortex A7
Antenna
- 2 x 2.4 GHz: 5 dBi
- 2 x 5 GHz: 5 dBi
- Detachable Omni-Directional Antenna
- SMA-Type
Physical Interface
- 1 x 10/100/1000 BASE-T, RJ-45 Gigabit Ethernet Port
- 1 x DC Jack
- 1 x Reset Button
LED Indicators
- 1 x Power
- 1 x LAN
- 1 x 2.4 GHz
- 1 x 5 GHz
Power Source
- Power-over-Ethernet: 802.3af Input
- IEEE 802.11e Compliant Source
- 12VDC /1A Power Adapter
Maximum Power Consumption
Surge Protection
|
Operating Frequency
- Dual-Radio Concurrent 2.4 GHz & 5 GHz
Operation Modes
- Access Point Mode (AP mode)
- WDS: WDS AP, WDS Bridge
Frequency Radio
- 2.4 GHz: 2400 MHz ~ 2472 MHz
- 5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz
Transmit Power
- Up to 15 dBm on 2.4 GHz
- Up to 15 dBm on 5 GHz
Tx Beamforming (TxBF)
- Radio Chains/Spatial Stream
- 2×2:2
SU-MIMO
- 2.4GHz – Two (2) Spatial Stream SU-MIMO up to 400 Mbps to individual 2×2
- VHT40 client devices (300 Mbps for HT40 802.11n client devices)
- 5GHz – Two (2) Spatial Stream SU-MIMO up to 867 Mbps to individual 2×2
- VHT40 client devices
MU-MIMO
- 5GHz – Two (2) Spatial Stream Multi User (MU) MIMO for up to 867Mbps to two (2) MU-MIMO capable wireless devices simultaneously
Supported Data Rates (Mbps):
- 2.4 GHz: Max 400
- 5 GHz: Max 867
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 36, 48, 54
- 802.11n: 6.5 to 300 Mbps (MCS0 to MCS15)
- 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)
Supported Radio Technologies
- 802.11b: Direct-Sequence Spread Spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal Frequency-Division Multiplexing (OFDM)
- 802.11n/ac: 2×2 MIMO with 2 Streams
Channelization
- 802.11ac Supports Very High Throughput (VHT)—VHT 20/40/80 MHz
- 802.11n Supports High Throughput (HT)—HT 20/40 MHz
- 802.11n Supports Very High Throughput (VHT) under the 2.4 GHz Radio—VHT 40 MHz (256-QAM)
- 802.11n/ac Packet Aggregation: AMPDU, ASPDU
Supported Modulation
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
- 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
|
|
Multiple BSSID
- Supports 16 SSIDs (8 SSIDs per Band)
VLAN Tagging
- Supports 802.1q SSID-to-VLAN Tagging
- Cross-Band VLAN Pass-Through
- Management VLAN
Spanning Tree
- Supports 802.1d Spanning Tree Protocol
QoS (Quality of Service)
- Complaint With IEEE 802.11e Standard
- WMM
Deployment Options
- Stand-Alone (Individually Managed)
- Managed Mode (w/ezMaster & Neutron Switch)
Stand-Alone Management Features
- Auto Channel Selection
- Auto Transmit Power
- Wireless STA (Client) Connected List
- Guest Network
- Fast Roaming (802.11k & 802.11r)
- Pre-Authentication (802.11i, 802.11x)
- PMK Caching (802.11i)
- RSSI Threshold
- Band Steering
- Traffic Shaping
- VLANs for Access Point – Multiple SSIDs
- Backup/Restore Settings
- Auto Reboot
- E-Mail Alert
- Site Survey
- Save Configuration as Default
Wireless Management Features (w/ezMaster & Neutron Switch)
- AP Auto Discovery & Provisioning
- AP Auto IP Assignment
- AP Group Management
- Auto AP Rebooting
- AP Device Name Editing
- AP Radio Settings
- Band Steering
- Traffic Shaping
- Fast Roaming (802.11k & 802.11r)
- Pre-Authentication (802.11i, 802.11x)
- PMK Caching (802.11i)
- RSSI Threshold
- AP Client Limiting
- Client Fingerprinting
- AP VLAN Management
- VLANs for AP – Multiple SSIDs
- Secured Guest Network
- Access Point Status Monitoring
- Wireless Client Monitoring
- Email Alert
- Wireless Traffic & Usage Statistics
- Real-Time Throughput Monitoring
- Visual Topology View
- Floor Plan View
- Map View
- Wireless Coverage Display
- Secure Control Messaging (SSL Certificate)
- Local MAC Address Database
- Remote MAC Address Database (RADIUS)
- Unified Configuration Import/Export
- Bulk Firmware Upgrade Capability
- One-Click Update
- Intelligent Diagnostics
- Kick/Ban Clients
- Wi-Fi Scheduler
Control Features
- Managed Mode (w/ezMaster/Neutron Switch)
- Distance Control (ACK Timeout)
- Multicast Supported
- Wi-Fi Scheduler
- Client Traffic Status
- RADIUS Accounting (802.1x)
- Power Save Mode (U-APSD Support)
- CLI Support
- HTTPS
Wireless Security
- WEP Encryption 64/128/152 bit
- WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES)
- Hide SSID in Beacons
- MAC Address Filtering, Up to 32 MACs per SSID
- Wireless STA (Client) Connected List
- SSH Tunnel
- Client Isolation
|
Temperature Range
- Operating: 32 ºF~104 ºF (0 ºC~40 ºC)
- Storage: -22 ºF~176 ºF (-30 ºC~80 ºC)
Humidity (non-condensing)
- Operating: 90% or less
- Storage: 90% or less
Dimensions & Weight
- Weight: 0.65 lbs. (0.29 kg)
- Diameter: 6.36” (161.54 mm)
- Height: 1.85” (41 mm)
Package Contents
- 1 – EnHero5 , AC1300 Indoor Access Point
- 1 – 12V/1A Power Adapter
- 1 – T-Rail Mounting Kits
- 1 – Ceiling and Wall Mount Screw Kits
- 1 – Mounting Brackets
- 1 – RJ-45 Ethernet Cables
- 1 – Quick Installation Guide
Certifications
|
