Thiết bị phát WiFi EnGenius EWS355AP
Product | EWS355AP |
---|---|
Technical Specifications | |
Standards | - IEEE 802.11b/g/n on 2.4 GHz - IEEE 802.11a/n/ac 5 GHz |
Processor | Qualcomm® 717 MHz Quad-Core CPU 4x ARM Cortex A7 |
Antenna | - 1 x 2.4 GHz: 5 dBi - 1 x 5 GHz: 5 dBi - Integrated Omni-Directional Antenna |
Physical Interface | - 1 x 10/100/1000 BASE-T, RJ-45 Gigabit Ethernet Port - 1x DC Jack - 1 x Reset Button |
LED Indicators | - 1 x Power - 1 x LAN - 1 x 2.4 GHz - 1 x 5 GHz |
Power Source | - Power-over-Ethernet: 802.3af Input - IEEE 802.11e Compliant Source - 12VDC/1A Power Adapter |
Maximum Power Consumption | 9 W |
Surge Protection | 0.5KV |
Wireless & Radio Specifications | |
Operating Frequency | Dual-Radio Concurrent 2.4 GHz & 5 GHz |
Operation Modes | - Access Point Mode - AP, AP Mesh, Mesh |
Frequency Radio | - 2.4 GHz: 2400 MHz ~ 2472 MHz - 5 GHz:
|
Transmit Power | - Up to 23 dBm on 2.4 GHz - Up to 23 dBm on 5 GHz |
Tx Beamforming (TxBF) | ✔ |
Radio Chains/Spatial Stream | 2x2:2 |
SU-MIMO | Two (2) Spatial Stream SU-MIMO up to 1267 Mbps to a single client |
MU-MIMO | Two (2) Spatial Stream MU-MIMO up to 867 Mbps to two (2) 1x1 wireless devices simultaneously |
Supported Data Rates (Mbps): | - 2.4 GHz: Max 400 - 5 GHz: Max 867 |
Management | |
Multiple BSSID | Supports 16 SSIDs, (8 per Band) |
VLAN Tagging | - Supports 802.1q SSID-to-VLAN Tagging - Cross-Band VLAN Pass-Through - Management VLAN |
Spanning Tree | Supports 802.1d Spanning Tree Protocol |
QoS (Quality of Service) | - Compliant with IEEE 802.11e Standard - WMM |
SNMP | v1, v2c, v3 |
MIB | I/II, Private MIB |
Wireless Security | - WEP Encryption 64/128/152 bit - WPA/WPA2 Enterprise (WPA-EAP Using TKIP or AES) - Hide SSID in Beacons - MAC Address Filtering, Up to 32 MACs per SSID - Wireless STA (Client) Connected List - SSH Tunnel - Client Isolation |
Deployment Options | - Stand-Alone (Individually Managed) - Managed Mode (with Neutron Series Switch/ezMaster) |
Environmental & Physical | |
Temperature Range | - Operating: 32ºF~104ºF (0ºC~40ºC) - Storage: -22ºF~176 ºF (-30ºC~80ºC) |
Humidity (non-condensing) | - Operating: 90% or less - Storage: 90% or less |
Device Dimensions & Weights | |
EWS355AP Device | - Weight: 0.80 lbs. (362.8 kg) - 6.5" (165.1 mm)(D) x 1.64" (41.6 mm)(H) |
Package Contents | 1 - EWS355AP Dual-Band AC1300 Indoor Access Point 1 - 12V/1A Power Adapter 1 - T-Rail Mounting Kits 1 - Ceiling and Wall Mount Screw Kits 1 - Mounting Brackets 1 - RJ-45 Ethernet Cables 1 - Quick Installation Guide |
Certifications | CE, FCC |
Elevate your business’s Wi-Fi with the EnGenius EWS355AP 11ac Wave 2 Managed Indoor Wireless Network Access Point (AP). It delivers blazing-fast 1.3 Gbps speeds and a higher user capacity. It supercharges performance up to 30% faster than traditional 3x3 APs. This dual-band AP improves connection reliability for exceptional next-generation, business-class Wi-Fi.
