FortiGate 100F UTP 3 Year (FG-100F-BDL-950-36)

Name: Fortinet FG-100F-BDL-950-36
Brand: Fortinet
SKU: FG-100F-BDL-950-36
Rating: 5 (47 reviews)

Question

Q

Quốc Trung - 2026-05-10

Mã FG-100F-BDL-950-36 có gì khác so với mã FG-100F-BDL-950-12 ? Giá có khác nhau nhiều không?

Thế Giới Mạng · Accepted Answer

Chào bạn, mã FG-100F-BDL-950-36 và FG-100F-BDL-950-12 hoàn toàn giống nhau cả về phần cứng và tính năng. Cả hai đểu tích hợp License Bundle FortiGuard Unified Threat Protection (UTP) : bao gồm IPS, Application Control, Web Filtering, Antivirus, Anti-Spam. Hậu tố 36: tích hợp license 36 tháng; Hậu tố 12: tích hợp license 12 tháng.

Về giá bạn có thể liên hệ với Kinh Doanh qua Zalo: 0906681689 / Email: info@thegioimang.vn để được hỗ trợ giá tốt nhé!

1 GE SFP LX transceiver module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 transceiver module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX transceiver module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
10 GE SFP+ transceiver module, short range	FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ RJ45 Transceiver Module	FN-TRAN-SFP+GC	10 GE SFP+ RJ45 transceiver module for systems with SFP+ slots
10 GE SFP+ Transceiver Module, Long Range	FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Passive Direct Attach Cable 1m	FN-CABLE-SFP+1	10 GE SFP+ passive direct attach cable, 1m for systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Passive Direct Attach Cable 3m	FN-CABLE-SFP+3	10 GE SFP+ passive direct attach cable, 3m for systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Passive Direct Attach Cable 5m	FN-CABLE-SFP+5	10 GE SFP+ passive direct attach cable, 5m for systems with SFP+ and SFP/SFP+ slots

Mã sản phẩm	FG-100F-BDL-950-36
Hardware Specifications
GE RJ45 Ports	12
GE RJ45 Management/HA /DMZ Ports	1 / 2 / 1
GE SFP Slots	4
10 GE SFP+ Slots	2
GE RJ45 WAN Ports	2
GE RJ45 or SFP Shared Ports	4
USB Port	1
Console Port	1
System Performance — Enterprise Traffic Mix
IPS Throughput ²	2.6 Gbps
NGFW Throughput ^{2, 4}	1.6 Gbps
Threat Protection Throughput ^{2, 5}	1 Gbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	20 / 18 / 10 Gbps
Firewall Latency (64 byte UDP packets)	4.97 μs
Firewall Throughput (Packets Per Second)	15 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	56,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)¹	11.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,500
Client-to-Gateway IPsec VPN Tunnels	16,000
SSL-VPN Throughput	1 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	500
SSL Inspection Throughput (IPS, avg. HTTPS) ³	1 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3	1,800
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3	135,000
Application Control Throughput (HTTP 64K)²	2.2 Gbps
CAPWAP Throughput (1444 byte, UDP)	15 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	128 / 64
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	44 x 432 x 254
Form Factor	Rack Mount, 1 RU
Weight	7.25 lbs (3.29 kg)
Environment
Power Required	100–240V AC, 60–50 Hz
Maximum Current	100V / 1A, 240V / 0.5A
Power Consumption (Average / Maximum)	26.5 W / 29.5 W
Heat Dissipation	100.6 BTU/h
Redundant Power Supplies	Yes (Default dual non-swappable AC PSU for 1+1 Redundancy)
Operating Temperature	32–104°F (0–40°C)
Operating Altitude	Up to 10 000 ft (3048 m)
Humidity	10–90% non-condensing
Noise Level	40.4 dBA
Compliance	FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
Certifications	USGv6/IPv6

Mã sản phẩm	FG-100F-BDL-950-36
Hardware Specifications
GE RJ45 Ports	12
GE RJ45 Management/HA /DMZ Ports	1 / 2 / 1
GE SFP Slots	4
10 GE SFP+ Slots	2
GE RJ45 WAN Ports	2
GE RJ45 or SFP Shared Ports	4
USB Port	1
Console Port	1
System Performance — Enterprise Traffic Mix
IPS Throughput ²	2.6 Gbps
NGFW Throughput ^{2, 4}	1.6 Gbps
Threat Protection Throughput ^{2, 5}	1 Gbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	20 / 18 / 10 Gbps
Firewall Latency (64 byte UDP packets)	4.97 μs
Firewall Throughput (Packets Per Second)	15 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	56,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)¹	11.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,500
Client-to-Gateway IPsec VPN Tunnels	16,000
SSL-VPN Throughput	1 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	500
SSL Inspection Throughput (IPS, avg. HTTPS) ³	1 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3	1,800
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3	135,000
Application Control Throughput (HTTP 64K)²	2.2 Gbps
CAPWAP Throughput (1444 byte, UDP)	15 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	128 / 64
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	44 x 432 x 254
Form Factor	Rack Mount, 1 RU
Weight	7.25 lbs (3.29 kg)
Environment
Power Required	100–240V AC, 60–50 Hz
Maximum Current	100V / 1A, 240V / 0.5A
Power Consumption (Average / Maximum)	26.5 W / 29.5 W
Heat Dissipation	100.6 BTU/h
Redundant Power Supplies	Yes (Default dual non-swappable AC PSU for 1+1 Redundancy)
Operating Temperature	32–104°F (0–40°C)
Operating Altitude	Up to 10 000 ft (3048 m)
Humidity	10–90% non-condensing
Noise Level	40.4 dBA
Compliance	FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
Certifications	USGv6/IPv6

Mã sản phẩm	FG-100F-BDL-950-36
Hardware Specifications
GE RJ45 Ports	12
GE RJ45 Management/HA /DMZ Ports	1 / 2 / 1
GE SFP Slots	4
10 GE SFP+ Slots	2
GE RJ45 WAN Ports	2
GE RJ45 or SFP Shared Ports	4
USB Port	1
Console Port	1
System Performance — Enterprise Traffic Mix
IPS Throughput ²	2.6 Gbps
NGFW Throughput ^{2, 4}	1.6 Gbps
Threat Protection Throughput ^{2, 5}	1 Gbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	20 / 18 / 10 Gbps
Firewall Latency (64 byte UDP packets)	4.97 μs
Firewall Throughput (Packets Per Second)	15 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	56,000
Firewall Policies	10,000
IPsec VPN Throughput (512 byte)¹	11.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,500
Client-to-Gateway IPsec VPN Tunnels	16,000
SSL-VPN Throughput	1 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	500
SSL Inspection Throughput (IPS, avg. HTTPS) ³	1 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 3	1,800
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3	135,000
Application Control Throughput (HTTP 64K)²	2.2 Gbps
CAPWAP Throughput (1444 byte, UDP)	15 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	128 / 64
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	44 x 432 x 254
Form Factor	Rack Mount, 1 RU
Weight	7.25 lbs (3.29 kg)
Environment
Power Required	100–240V AC, 60–50 Hz
Maximum Current	100V / 1A, 240V / 0.5A
Power Consumption (Average / Maximum)	26.5 W / 29.5 W
Heat Dissipation	100.6 BTU/h
Redundant Power Supplies	Yes (Default dual non-swappable AC PSU for 1+1 Redundancy)
Operating Temperature	32–104°F (0–40°C)
Operating Altitude	Up to 10 000 ft (3048 m)
Humidity	10–90% non-condensing
Noise Level	40.4 dBA
Compliance	FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI
Certifications	USGv6/IPv6
