Mã sản phẩm	FG-400F-BDL-950-12
Interfaces and Modules
Hardware Accelerated GE RJ45 Interfaces	16
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated 10GE SFP+ Slots	4
Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots	4
GE RJ45 Management Ports	2
USB Ports	1
RJ45 Console Port	1
Onboard Storage	0
Trusted Platform Module (TPM)	Yes
Included Transceivers	2x SFP (SX 1 GE)
System Performance — Enterprise Traffic Mix
IPS Throughput	12 Gbps
NGFW Throughput	10 Gbps
Threat Protection Throughput	9 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP)	79.5 / 78.5 / 70 Gbps
IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP)	79.5 / 78.5 / 70 Gbps
Firewall Latency (64 byte, UDP)	4.19 μs / 2.5 μs
Firewall Throughput (Packets Per Second)	105 Mpps
Concurrent Sessions (TCP)	7.8 Million
New Sessions/Second (TCP)	500 000
Firewall Policies	10 000
IPsec VPN Throughput (512 byte)	55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2000
Client-to-Gateway IPsec VPN Tunnels	50 000
SSL-VPN Throughput	3.6 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	5000
SSL Inspection Throughput (IPS, avg. HTTPS)	8 Gbps
SSL Inspection CPS (IPS, avg. HTTPS)	6 000
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	800 000
Application Control Throughput (HTTP 64K)	28 Gbps
CAPWAP Throughput (HTTP 64K)	65 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of FortiSwitches Supported	72
Maximum Number of FortiAPs (Total / Tunnel)	512 / 256
Maximum Number of FortiTokens	5 000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Dimensions
Height x Width x Length (inches)	1.75 x 17.0 x 15.0
Height x Width x Length (mm)	44.45 x 432 x 380
Weight	14.11 lbs (6.4 kg)
Form Factor	Rack Mount, 1 RU
AC Power Consumption (Average / Maximum)	154.8 W / 189.2 W
AC Power Input	100–240V AC, 50/60Hz
AC Current (Maximum)	6A
Heat Dissipation	645.58 BTU/h
Power Supply Efficiency Rating	80Plus Compliant
Redundant Power Supplies (Hot Swappable)	Yes (Default dual AC PSU for 1+1 Redundancy)
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	5–90% non-condensing
Noise Level	LPA 48 dBA / LWA 55 dBA
Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6

Các phụ kiện và Module dùng với FortiGate 400F

Optional Accessories	SKU	Description
1 GE SFP LX Transceiver Module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots
1 GE SFP RJ45 Transceiver Module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots
1 GE SFP SX Transceiver Module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
10 GE SFP+ RJ45 Transceiver Module	FN-TRAN-SFP+GC	10 GE SFP+ RJ45 transceiver module for systems with SFP+ slots
10 GE SFP+ Transceiver Module, Short Range	FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Long Range	FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots
10 GE SFP+ Transceiver Module, Extended Range	FN-TRAN-SFP+ER	10 GE SFP+ transceiver module, extended range for all systems with SFP+ and SFP/SFP+ slots
AC power adaptor	SP-FG400F-PS	AC power supply for FG-400/401F, FG-600/601F, power cable SP-FGPCOR-XX sold separately

Hardware Plus Forticare Premium and FortiGuard UTP - 1 Year Subscription (FG-400F-BDL-950-12)
- Hardware: 18 x GE RJ45 ports (including 1 x MGMT port, 1 X HA port, 16 x switch ports), 8 x GE SFP slots, 8 x 10GE
SFP+ slots, SPU NP7 and CP9 hardware accelerated, dual AC power supplies.
- 1 Year Hardware Unit plus FortiCare Premium Ticket Handling, Advanced Hardware Replacement (NBD), Firmware and General Upgrades, UTP Services Bundle (IPS, AV, Botnet IP/Domain, Mobile Malware, FortiGate Cloud Sandbox including Virus Outbreak and Content Disarm & Reconstruct, Application Control, Web & Video Filtering and Antispam Service) plus term of contract

Data sheet Firewall Fortinet FortiGate 400F Series
