FortiGate 60F UTP 1 Year (FG-60F-BDL-950-12)

FG-60F-BDL-950-12 thiết bị tường lửa Fortinet FortiGate 60F Plus 1 Year 24x7 Forticare and Fortiguard UTP

  • Recommended: for 11-60 User Network
  • Threat Protection Throughput: 700 Mbps
  • Site-to-Site VPN Tunnels: 200
  • Concurrent Sessions: 700,000
  • 1 Year Services: 24x7 FortiCare & FortiGuard Unified Threat Protection (UTP)
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng

Thiết bị tường lửa Firewall Fortinet FortiGate-60F (FG-60F-BDL-950-12)

Mã sản phẩm FG-60F-BDL-950-12
Hardware Specifications
GE RJ45 WAN / DMZ Ports 2 / 1
GE RJ45 Internal Ports 5
GE RJ45 FortiLink Ports 2
GE RJ45 PoE/+ Ports -
Wireless Interface -
Console Port 1
USB Port 1
Internal Storage -
System Performance — Enterprise Traffic Mix
IPS Throughput 1.4 Gbps
NGFW Throughput 1 Gbps
Threat Protection Throughput 700 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets) 10/10/6 Gbps
Firewall Latency (64 byte, UDP) 3.3 μs
Firewall Throughput (Packet per Second) 9 Mpps
Concurrent Sessions (TCP) 700,000
New Sessions/Sec (TCP) 35,000
Firewall Policies 5,000
IPsec VPN Throughput (512 byte) 6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels 200
Client-to-Gateway IPsec VPN Tunnels 500
SSL-VPN Throughput 900 Mbps
Concurrent SSL-VPN Users 200
SSL Inspection Throughput (IPS, HTTP) 630 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 400
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 55,000
Application Control Throughput 1.8 Gbps
CAPWAP Throughput (1444 byte, UDP) 8 Gbps
Virtual Domains (Default / Maximum) 10 / 10
Maximum Number of Switches Supported 16
Maximum Number of FortiAPs (Total / Tunnel Mode) 64 / 32
Maximum Number of FortiTokens 500
High Availability Configurations Active / Active, Active / Passive, Clustering
Dimensions and Power
Height x Width x Length (inches) 1.5 x 8.5 x 6.3
Height x Width x Length (mm) 38.5 x 216 x 160
Weight 2.23 lbs (1.01 kg)
Operating Environment and Certifications
Power Rating 12Vdc, 3A
Power Required Powered by External DC Power Adapter, 100–240V AC, 50–60 Hz
Maximum Current 100Vac/1.0A
Power Consumption (Average / Maximum) 17.0 W / 18.5 W
Heat Dissipation 63.1 BTU/hr
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -31–158°F (-35–70°C)
Humidity 10–90% non-condensing
Noise Level Fanless 0 dBA
Operating Altitude Up to 7,400 ft (2,250 m)
Certifications ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

Tùy chọn phụ kiện FortiGate 60F

Accessories SKU Description
AC Power Adaptor SP-FG60E-PDC-5 Pack of 5 AC power adaptors for FG/FWF 60E/61E, 60F/61F, and 80E/81E
Rack Mount Tray SP-RACKTRAY-02 Rack mount tray for all FortiGate E series and F series desktop models are backwards compatible with SP-RackTray-01
Wall Mount Kit SP-FG60F-MOUNT-20 Pack of 20 wall mount kits for FG/FWF-60F and FG/FWF-80F series


Hardware plus 1 Year 24x7 FortiCare and FortiGuard UTP Bundle (FG-60F-BDL-950-12)
- Hardware: 10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port). Maximum managed FortiAPs (Total / Tunnel) 30 / 10;
- 1 Year Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP) (IPS, Advanced Malware Protection, Application Control, Web & Video Filtering, Antispam Service)

Data sheet Fortinet Fortigate 60F
