FortiGate 80F UTP 3 Year (FG-80F-BDL-950-36)

Name: Fortinet FG-80F-BDL-950-36
Brand: Fortinet
SKU: FG-80F-BDL-950-36
Rating: 5 (36 reviews)

Question

H

Hữu Phước - 2026-05-10

Mã FG-80F-BDL-950-36 có gì khác so với mã FG-80F-BDL-950-12 ? Giá mã nó như thế nào?

Thế Giới Mạng · Accepted Answer

Chào bạn, mã FG-80F-BDL-950-36 và FG-80F-BDL-950-12 hoàn toàn giống nhau cả về phần cứng và tính năng. Cả hai đểu tích hợp License Bundle FortiGuard Unified Threat Protection(UTP): bao gồm IPS, Application Control, Web Filtering, Antivirus, Anti-Spam. Hậu tố 36: tích hợp license 36 tháng; Hậu tố 12: tích hợp license 12 tháng.

Về giá bạn có thể liên hệ với Kinh Doanh qua Zalo: 0906681689 / Email: info@thegioimang.vn để được hỗ trợ giá tốt nhé!

Accessories	SKU	Description
AC power adaptor	SP-FG60E-PDC-5	Pack of 5 AC power adaptors for FG/FWF 60E/61E, 60F/61F, 80E/81E and 80F/81F
Rack Mount Tray	SP-RACKTRAY-02	Rack mount tray for all FortiGate E series and F series desktop models
Wall Mount Kit	SP-FG60F-MOUNT-20	Pack of 20 wall mount kits for FG/FWF-40F series, FG/FWF-60F series, FG-80F, FG-81F and FG-80F-Bypass
Transceivers	SKU	Description
1 GE SFP RJ45 Transceiver Module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
1 GE SFP SX Transceiver Module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP LX Transceiver Module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.

Mã sản phẩm	FG-80F-BDL-950-36
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 Internal Ports	6
GE RJ45 FortiLink Ports (Default)	2
Bypass GE RJ45 Port Pair (WAN1 & Port1, default configuration)	-
USB Ports 3.0	1
Console (RJ45)	1
Trusted Platform Module (TPM)	Yes
Bluetooth Low Energy (BLE)	Yes
System Performance — Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	10/10/7 Gbps
Firewall Latency (64 byte UDP packets)	3.23 μs
Firewall Throughput (Packets Per Second)	10.5 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	2,500
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	200
SSL Inspection Throughput (IPS, HTTP)	715 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)	700
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	100,000
Application Control Throughput (HTTP 64K)	1.8 Gbps
CAPWAP Throughput (HTTP 64K)	9 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	96 / 48
Maximum Number of FortiTokens	500
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	40 x 216 x 178
Weight	2.4 lbs (1.1 kg)
Form Factor	Desktop / Wall Mount / Rack Tray
Operating Environment and Certifications
Input Rating	12V DC, 3A (dual redundancy optional)
Power Required	Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Power Consumption (Average / Maximum)	12.69 W / 15.51 W
Heat Dissipation	52.55 BTU/h
Operating Temperature	32–104°F (0–40°C)
Humidity	10–90% non-condensing
Noise Level	Fanless 0 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

Mã sản phẩm	FG-80F-BDL-950-36
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 Internal Ports	6
GE RJ45 FortiLink Ports (Default)	2
Bypass GE RJ45 Port Pair (WAN1 & Port1, default configuration)	-
USB Ports 3.0	1
Console (RJ45)	1
Trusted Platform Module (TPM)	Yes
Bluetooth Low Energy (BLE)	Yes
System Performance — Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	10/10/7 Gbps
Firewall Latency (64 byte UDP packets)	3.23 μs
Firewall Throughput (Packets Per Second)	10.5 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	2,500
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	200
SSL Inspection Throughput (IPS, HTTP)	715 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)	700
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	100,000
Application Control Throughput (HTTP 64K)	1.8 Gbps
CAPWAP Throughput (HTTP 64K)	9 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	96 / 48
Maximum Number of FortiTokens	500
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	40 x 216 x 178
Weight	2.4 lbs (1.1 kg)
Form Factor	Desktop / Wall Mount / Rack Tray
Operating Environment and Certifications
Input Rating	12V DC, 3A (dual redundancy optional)
Power Required	Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Power Consumption (Average / Maximum)	12.69 W / 15.51 W
Heat Dissipation	52.55 BTU/h
Operating Temperature	32–104°F (0–40°C)
Humidity	10–90% non-condensing
Noise Level	Fanless 0 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6

Mã sản phẩm	FG-80F-BDL-950-36
Hardware Specifications
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 Internal Ports	6
GE RJ45 FortiLink Ports (Default)	2
Bypass GE RJ45 Port Pair (WAN1 & Port1, default configuration)	-
USB Ports 3.0	1
Console (RJ45)	1
Trusted Platform Module (TPM)	Yes
Bluetooth Low Energy (BLE)	Yes
System Performance — Enterprise Traffic Mix
IPS Throughput	1.4 Gbps
NGFW Throughput	1 Gbps
Threat Protection Throughput	900 Mbps
System Performance
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	10/10/7 Gbps
Firewall Latency (64 byte UDP packets)	3.23 μs
Firewall Throughput (Packets Per Second)	10.5 Mpps
Concurrent Sessions (TCP)	1.5 Million
New Sessions/Second (TCP)	45,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	6.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	2,500
SSL-VPN Throughput	950 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	200
SSL Inspection Throughput (IPS, HTTP)	715 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)	700
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	100,000
Application Control Throughput (HTTP 64K)	1.8 Gbps
CAPWAP Throughput (HTTP 64K)	9 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	24
Maximum Number of FortiAPs (Total / Tunnel Mode)	96 / 48
Maximum Number of FortiTokens	500
High Availability Configurations	Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (mm)	40 x 216 x 178
Weight	2.4 lbs (1.1 kg)
Form Factor	Desktop / Wall Mount / Rack Tray
Operating Environment and Certifications
Input Rating	12V DC, 3A (dual redundancy optional)
Power Required	Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Power Consumption (Average / Maximum)	12.69 W / 15.51 W
Heat Dissipation	52.55 BTU/h
Operating Temperature	32–104°F (0–40°C)
Humidity	10–90% non-condensing
Noise Level	Fanless 0 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications	USGv6/IPv6
