Name: Fortinet FG-900G-BDL-811-12
Brand: Fortinet
SKU: FG-900G-BDL-811-12
Rating: 5 (33 reviews)

Hỗ trợ trực tuyến

Tư vấn

Hỗ trợ Tư Vấn

0909648899

Kinh doanh

Kinh Doanh 01

0917684899

Kinh Doanh 02

0917993131

Kinh Doanh 03

0915793030

Kinh Doanh 04

0906641689

Kỹ thuật

Hỗ trợ Kỹ Thuật 1

02862578356

Hỗ trợ Kỹ Thuật 2

02862578355

Mô tả sản phẩm

Thiết bị tường lửa Firewall FortiGate-901F Enterprise (FG-901G-BDL-811-12 )

Giao diện: 4x 25G SFP28, 4 x 10GE SFP+, 17 x GE RJ45, 8 x GE SFP slots
Thông lượng Firewall: 164 Gbps
Thông lượng IPS: 42 Gbps
Thông lượng NGFW: 31 Gbps
Thông lượng Threat Protection: 30 Gbps

Hardware Plus 1 Year Forticare & FortiGuard Enterprise Protection (FG-900G-BDL-811-12)

- Hardware: 4x 25G SFP28 slots, 4 x 10GE SFP+ slots, 17 x GE RJ45 ports (including 1 x MGMT port, 16 x switch ports), 1 X 2.5G HA port, 8 x GE SFP slots, SPU NP7 and CP9 hardware accelerated, dual AC PSU.
- 1 Year Hardware Unit plus FortiCare Premium Ticket Handling, Advanced Hardware Replacement (NBD), Firmware and General Upgrades, Enterprise Services Bundle (IPS, AV, Botnet IP/Domain, Mobile Malware, FortiGate Cloud Sandbox including Virus Outbreak and Content Disarm & Reconstruct, Application Control, Web & Video Filtering, Antispam, Security Rating, Industrial Security and FortiConverter Service) plus term of contract.

Các phụ kiện và Module dùng với FortiGate 900G

Optional Accessories	SKU	Description
AC Power Supply	SP-FG400F-PS	AC power supply for FG-400/401F, FG-600/601F, and FG-900/901G; power cable SP-FGPCOR-XX sold separately.
DC Power Supply	SP-FG400F-DC-PS	DC power supply for FG-400/401F-DC and FG-900/901G-DC, comes with 3m DC cable.
Transceivers
1 GE SFP LX Transceiver Module	FN-TRAN-LX	1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP RJ45 Transceiver Module	FN-TRAN-GC	1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+ slots.
1 GE SFP SX Transceiver Module	FN-TRAN-SX	1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots.
10 GE SFP+ RJ45 Transceiver Module	FN-TRAN-SFP+GC	10 GE SFP+ RJ45 transceiver module for systems with SFP+ slots.
10 GE SFP+ Transceiver Module, Short Range	FN-TRAN-SFP+SR	10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Long Range	FN-TRAN-SFP+LR	10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Extended Range	FN-TRAN-SFP+ER	10 GE SFP+ transceiver module, extended range for all systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, 30km Long Range	FN-TRAN-SFP+BD27	10 GE SFP+ transceiver module, 30km long range single BiDi (connects to FN-TRAN-SFP+BD33, ordered separately).
10 GE SFP+ Transceiver Module	FN-TRAN-SFP+BD33	10 GE SFP+ transceiver module, 30km long range single BiDi (connects to FN-TRAN-SFP+BD27, ordered separately).
10 GE SFP+ Transceiver Module, 80km Extreme Long Range	FN-TRAN-SFP+ZR	10 GE SFP+ transceiver module, 80km extreme long range for systems with SFP+ and SFP/SFP+ slots.
10 GE SFP+ Transceiver Module, Extended Range	FS-TRAN-SFP+ER	10 GE SFP+ transceivers, extended range for all systems with SFP+ slots.
25 GE SFP28 Transceiver Module, Short Range	FN-TRAN-SFP28-SR	25 GE SFP28 transceiver module, short range for all systems with SFP28 slots.
25 GE SFP28 Transceiver Module, Long Range	FN-TRAN-SFP28-LR	25 GE SFP28 transceiver module, long range for all systems with SFP28 slots.
Cables
10 GE SFP+ Active Direct Attach Cable, 10m / 32.8 ft	SP-CABLE-ADASFP+	10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots.
25 GE SFP28 Passive Direct Attach Cable	FN-CABLE-SFP28-1	25 GE SFP28 passive direct attach cable 1m for systems with SFP28 slots.
25 GE SFP28 Passive Direct Attach Cable	FN-CABLE-SFP28-3	25 GE SFP28 passive direct attach cable 3m for systems with SFP28 slots.
25 GE SFP28 Passive Direct Attach Cable	FN-CABLE-SFP28-5	25 GE SFP28 passive direct attach cable 5m for systems with SFP28 slots.

Xem thêm

Thông số kỹ thuật

Specification	FG-900G / FG-900G-DC
Interfaces and Modules
Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Ultra Low Latency Slots	4
Hardware Accelerated 10 GE SFP+ / GE SFP Slots	4
Hardware Accelerated GE SFP Slots	8
Hardware Accelerated GE RJ45 Slots	16
2.5 GE / GE HA Port	1
GE Management Port	1
USB Ports (Client / Server)	2/2
Console Port	1
Onboard Storage	No
Trusted Platform Module (TPM)	Yes
Bluetooth Low Energy (BLE)	Yes
Signed Firmware Hardware Switch	-
Included Transceivers	2 × SFP SX
System Performance – Enterprise Traffic Mix
IPS Throughput	42 Gbps
NGFW Throughput	31 Gbps
Threat Protection Throughput	30 Gbps
System Performance and Capacity
IPv4 Firewall Throughput (1518/512/64 byte UDP packets)	164 / 163 / 153 Gbps
IPv6 Firewall Throughput (1518/512/86 byte UDP packets)	164 / 163 / 153 Gbps
Firewall Latency (64 byte UDP packets)	3.78 µs / 2.5 µs*
Firewall Throughput (Packets Per Second)	229.5 Mpps
Concurrent Sessions (TCP)	16 Million
New Sessions/Second (TCP)	720,000
Firewall Policies	50,000
IPsec VPN Throughput (512 byte)	55 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	2,000
Client-to-Gateway IPsec VPN Tunnels	50,000
SSL-VPN Throughput	10 Gbps
Concurrent SSL-VPN Users (Tunnel Mode)	10,000
SSL Inspection Throughput	16.7 Gbps
SSL Inspection CPS	18,000
SSL Inspection Concurrent Session	1.6 Million
Application Control Throughput	74.8 Gbps
CAPWAP Throughput	133 Gbps
Virtual Domains (Default/Maximum)	10/50
Maximum Number of FortiSwitches Supported	196 **
Maximum Number of FortiAPs (Total/Tunnel Mode)	2048 / 1024
Maximum Number of FortiTokens	5,000
High Availability Configurations	Active-Active, Active-Passive, Clustering
Dimensions and Power
Height x Width x Length (inches)	1.5 × 17.0 × 15.0
Height x Width x Length (mm)	44.45 × 432 × 380
Weight	15.98 lbs (7.25 kg)
Form Factor	Rack Mount, 1 RU
AC Power Supply	100–240VAC, 50/60 Hz
AC Current (Maximum)	6A @100VAC
DC Power Supply	48–60VDC
DC Current (Maximum)	7A @48V
Power Consumption (Average/Maximum)	170 W / 313 W
Heat Dissipation	1069 BTU/h
Power Supply Efficiency Rating	80Plus Compliant
Redundant Power Supplies (Hot Swappable)	Yes (comes with 2 PSU default)
Operating Environment and Certifications
Operating Temperature	32ºF to 113ºF (0°–45°C)
Storage Temperature	-31ºF to 158ºF (-35°–70°C)
Humidity	10% to 90% non-condensing
Noise Level	58 dBA
Airflow	Side and Front to Back
Operating Altitude	Up to 10,000 ft (3048 m)
Compliance	FCC Part 15 Class A, RCM, VCCI, CE, UL/CUL, CB
Certifications	USGv6/IPV6

Download file Datasheet

Xem thêm thông số kỹ thuật
