Juniper EX4100-48P

Juniper EX4100-48P Ethernet PoE+ Access Switch :

  • 48 x 10/100/1000BASE-T PoE+ ports
  • 4 x 10GbE uplinks
  • 4 x 25GbE stacking/uplink ports
  • PoE Budget 1 PSU/2 PSU : 740 W/1440 W
  • MACsec AES256
  • Redundant fans
  • 1 x JPSU-920-AC-AFO included
  • Standard license
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị chuyển mạch Switch Juniper EX4100-48P

Model EX4100-48P
Switching Engine Mode • Store and forward
Memory • DRAM: 4 GB with Error Correcting Code (ECC)
• Storage: 8 GB
CPU • 1.7 GHz ARM CPU
Port Density per System • 48 1GbE host ports + 4 10GbE/25GbE ports + 4 1GbE/10GbE ports
Packet Switching Capacities
(Maximum with 64 Byte Packets)
• 188 Gbps (unidirectional)/376 Gbps (bidirectional)
Layer 2/Layer 3 Throughput (Mpps)
(Maximum with 64 Byte Packets)
• 279 Mpps
Backplane • 200 Gbps Virtual Chassis interconnect to combine up to 10 units as a single logical device
Power Options • Power supplies: Autosensing; 100-120 V/200-240 V; 920 W AC AFO, dual load sharing hot-swappable internal redundant power supplies
• Maximum current inrush: 30 amps
• Minimum number of PSUs required for fully loaded chassis: 1 per switch
Dimensions (W x H x D) • Base Unit: 44.1 x 4.37 x 35 cm
• With power supply installed: 44.1 x 4.37 x 38.24 cm
• Height: 1 U
System Weight • Switch with no power supply or fan module : 4.66 kg
• 920 W AC power supply: 0.85 kg
• Fan module: 0.07 kg
Environmental Ranges • Operating temperature: 32° to 113° F (0° to 45° C)
• Storage temperature: -40° to 158° F (-40° to 70° C)
• Operating altitude: Up to 5000 ft at 40° C (1828.8 m)
• Nonoperating altitude: Up to 16,000 ft (4877 m)
• Relative humidity operating: 5% to 90% (noncondensing)
• Relative humidity non-operating: 0% to 90% (noncondensing)
Cooling • Field-replaceable fans: 2

EX4100-48P : 48-port 10/100/1000BASE-T PoE+ switch, 4x10GbE uplinks, 4x25GbE stacking/uplink ports, MACsec AES256, redundant fans, 1x JPSU-920-AC-AFO included with Standard SW. optics sold separately, TAA-compliant.

Data sheet Juniper EX4100 Line Of Ethernet Switches
