Juniper MX80BASE-P

Router Juniper MX80BASE-P : MX80 chassis with PTP and Synchronous Ethernet support - includes one power supply, 2 empty MIC slots, 4x10GbE 10-gigabit small form-factor pluggable transceiver (XFP) built-in ports, fan tray with filter. Power supply cable needs to be ordered separately.
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị định tuyến Router Juniper MX80BASE-P

Model MX80BASE-P
Layout
System capacity 80 Gbps
Slot orientation Horizontal
Mounting Front or center
Physical Specification
Dimensions (W x H x D) 17.5 x 3.5 x 23.46 in (44.5 x 8.9 x 59.6 cm)
Weight fully loaded 30 lb/13.7 kg
Weight unloaded NA
Routing Engine
Default memory 8 MB boot flash; 4GB on NAND flash storage; 2 GB of DDR2 RAM
Number of cores 1 core
Redundancy Power supplies and fans
Environmental
Air flow Side to side [forced air]
Operating temperature 32° to 115° F (0° to 46° C) at sea level
Operating humidity 5% to 90%
Operating altitude 10,000 ft (3048 m)
Certifications GR-63-Core Physical Protection
GR-1089-Core:EMC and Electrical Safety

MX80 Software Licenses

S-MX80-ADV-R License to support full scale L3 route and L3 VPN on MX80
S-MX80-Q License to support per VLAN queuing on MX80
S-MX80-SA-FP Subscriber Management Feature Pack License
S-MX80-SSM-FP Subscriber Service Management Feature Packet License (RADIUS/SRC Series-based service activation and deactivation) per service accounting features for subscribers, MX80

MX80BASE-P : MX80 chassis with PTP and Synchronous Ethernet support—includes one power supply, 2 empty MIC slots, 4x10GbE 10-gigabit small form-factor pluggable transceiver (XFP) built-in ports, fan tray with filter. Power supply cable needs to be ordered separately.

Data sheet MX Series Universal Routing Platforms
