Mô tả sản phẩm

Thiết bị tường lửa Firewall Juniper SRX380 (SRX380-P-SYS-JB-AC)

Model	SRX380 (SRX380-P-SYS-JB-AC)
Connectivity
Total onboard ports	20 (16x1GbE, 4x10GbE)
Onboard RJ-45 ports	16x1GbE
Onboard (SFP) transceiver ports	4x10GbE SFP+
MACsec-capable ports	• 16x1GbE • 4x10GbE
Out-of-band (OOB) management ports	1x1GbE
Mini PIM (WAN) slots	4
Console (RJ-45 + miniUSB)	1
USB 3.0 ports (type A)	1
PoE+ ports	16
Memory and Storage
System memory (RAM)	4GB
Storage	100GB SSD
SSD slots	1
Performance and Scale
Routing with packet mode (64 B packet size) in Mbps	1700
Routing with packet mode (IMIX packet size) in Mbps	5000
Routing with packet mode (1,518 B packet size in Mbps)	10000
Stateful firewall (64 B packet size) in Kpps	1700
Stateful firewall (IMIX packet size) in Mbps	6500
Stateful firewall (1,518 B packet size) in Mbps	20000
IPsec VPN (IMIX packet size) in Mbps	1400
IPsec VPN (1,400 B packet size) in Mbps	4400
Application visibility and control in Mbps	6000
Recommended IPS in Mbps	2000
Next-generation firewall in Mbps	2500
Secure Web Access firewall in Mbps	1800
Route table size (RIB/FIB) (IPv4 or IPv6)	1 million/600,000
Maximum concurrent sessions (IPv4 or IPv6)	380000
Maximum security policies	4000
Connections per second	50000
NAT rules	3000
MAC table size	16000
IPsec VPN tunnels	2048
Number of remote access/SSL VPN (concurrent) users	500
GRE tunnels	2048
Maximum number of security zones	128
Maximum number of virtual routers	128
Maximum number of VLANs	3000
AppID sessions	64000
IPS sessions	64000
URLF sessions	64000
Dimensions and Power
Form factor	1 U
Size (WxHxD)	44.09 x 4.37 x 47.5 cm / 44.09 x 4.37 x 52 cm
Weight (device and PSU)	6.8 kg with 1xPSU / 7.6 kg with 2xPSU
Redundant PSU	Yes
Power supply	1+1 hot-swappable AC PSU
Rated DC voltage range	NA
Rated DC operating voltage range	N/A
Maximum PoE power	480W
Average power consumption	• 150 W (without PoE) • 510 W (with PoE)
Average heat dissipation	511.5 BTU/hr (without PoE)
Maximum current consumption	1.79A/7.32A
Acoustic noise level	< 50dBA @ room temperature 27C
Airflow/cooling	Front to back
Environmental, Compliance, and Safety Certification
Operational temperature	• 32° to 104° F (0° to 40° C) with MPIMs • 32° to 122° F (0° to 50° C) without MPIMs
Nonoperational temperature	-4° to 158° F (-20° to 70° C)
Operating humidity	10% to 90% noncondensing
Nonoperating humidity	5% to 95% non-condensing
Meantime between failures (MTBF)	28.1 years
FCC classification	Class A
RoHS compliance	RoHS 2
FIPS 140-2	Level 2 (Junos 20.2R1)
Common Criteria certification	NDPP, VPNEP, FWEP, IPSEP (based on Junos 20.4R1)

Xem thêm

Thông số kỹ thuật

SRX380-P-SYS-JB-AC : SRX380 Firewalls include hardware (16GbE PoE+, 4x10GbE, 4x MPIM slots, 4GB RAM, 100GB SSD, single AC power supply, cable and RMK) and Junos Software Base (firewall, NAT, IPSec, routing, MPLS and switching)

Data sheet Juniper SRX300 Line of Firewalls for the Branch

Xem thêm thông số kỹ thuật
