Máy chủ Dell PowerEdge R450 - 4 x 3.5" ● Chassis Dell PowerEdge T550 3.5inch - 1 X 1100W Power Supply 8x HDD HotSwap ● Dell PowerEdge RAID Controller PERC H755 ● 1 x Intel® Xeon® Silver 4310 Processor (18M Cache, 2.10 GHz) ● 1 x RAM DELL 16GB PC4-3200AA DDR4-3200MHz ECC Registered ● 1 x HDD Dell 2TB 3.5inch 7.2K RPM NLSAS 12Gb/s

Giá bán : Liên hệ để có giá tốt
Tình trạng : Còn hàng

Thông số kỹ thuật
Tài liệu liên quan

Máy chủ Dell PowerEdge R450 - 4 x 3.5"

Chassis Dell PowerEdge T550 3.5inch - 1 X 1100W Power Supply 8x HDD HotSwap
Mainboard Dell PowerEdge T550
Dell PowerEdge RAID Controller PERC H755
1 x Intel® Xeon® Silver 4310 Processor (18M Cache, 2.10 GHz)
1 x Bộ Nhớ RAM DELL 16GB PC4-3200AA DDR4-3200MHz ECC Registered
1 x Ổ Cứng HDD Dell 2TB 3.5inch 7.2K RPM NLSAS 12Gb/s
1 x Heatsink Dell PowerEdge T550
1 x Tray Dell 3.5 inch 14G/15G Caddy

Data sheet Dell PowerEdge R450

Cấu hình kỹ thuật chung PowerEdge R450

Server	PowerEdge R450
Idear for	• Small IT Infrastructure • Light VM (virtual machine density) • Small Business Specific
Processor	Up to two 3rd Generation Intel Xeon Scalable processors, with up to 24 cores per processor
Memory	Memory 16 DDR4 DIMM slots, supports RDIMM max 1 TB, speeds up to 2933 MT/s
Storage controllers	• Internal controllers (RAID): PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150 • Internal Boot: Internal Dual SD Module or Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2x M.2 SSDs or USB • External PERC (RAID): PERC H840 • External HBA (non-RAID) HBA355e
Drive bays	Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 61.4 TB
Power supplies	• 1100 W DC / -48–(-60) V • 800 W Platinum AC 100-240 VAC or 240 VDC HVDC, hot-swap redundant • 600 W Platinum AC 100-240 VAC or 240 VDC HVDC, hot-swap redundant
Cooling options	Air cooling
Fans	• Standard (STD) fans or High performance SLVR fans • Up to seven cold swap fans
Dimension	• Height: 42.8 mm (1.7 inches) • Width: 482 mm (18.97 inches) • Depth: 734.95 mm (28.92 inches) – without bezel 748.79 mm (29.47 inches) – with bezel
Form Factor	1U rack server
Embedded management	• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module • Quick Sync 2 wireless module
Bezel	Optional LCD bezel or security bezel
OpenManage Software	• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin
Mobility	OpenManage Mobile
Integrations and Connections	OpenManage Integrations: • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules • VMware vCenter and vRealize Operations Manager OpenManage Connections: • IBM Tivoli Netcool/OMNIbus • IBM Tivoli Network Manager IP Edition • Micro Focus Operations Manager • Nagios Core • Nagios XI
Security	• Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC	2 x 1 GbE LOM
Network Options	1 x OCP 3.0
Ports	Front Ports: • 1 x Dedicated iDRAC Direct micro-USB • 1 x USB 3.0 • 1 x VGA Internal Ports: • 1 x USB 3.0 (optional) Rear Ports: • 1 x USB 2.0 • 1 x Serial (optional) • 1 x iDRAC ethernet port • 1 x USB 3.0 • 2 x Ethernet • 1 x VGA
PCIe	2 x PCIe Gen4 slots + PCIe Gen • 2 x16 Gen4 (x16 connector) low profile, half length • 1 x4 Gen3 (x8 connector) low profile, half length
Operating System and Hypervisors	• Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi
