Thiết bị định tuyến Mikrotik CRS310-1G-5S-4S+IN
| Product code | CRS310-1G-5S-4S+IN |
|---|---|
| Specifications | |
| CPU | 98DX226S 800 MHz |
| CPU architecture | ARM 32bit |
| CPU core count | 1 |
| Size of RAM | 256 GB |
| RAM type | DDR3 |
| Storage | 16 MB, Flash |
| Number of 1G Ethernet ports | 1 |
| Number of 1G SFP ports | 5 |
| Number of 10G SFP+ ports | 4 |
| Switch chip model | 98DX226S |
| Dimensions | 200 x 166 x 45 mm |
| Operating system | RouterOS, License level 5 |
| Operating temparature | -40°C to +70°C |
| Powering | |
| Number of DC inputs | 2 (PoE-in, DC jack) |
| PoE-in input Voltage | 18-57 V |
| DC jack input Voltage | 18-57 V |
| Power adapter nominal voltage | 24 V |
| Power adapter nominal current | 1.2 A |
| Max power consumption without attachments | 8 W |
| Max power consumption | 20 W |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | 20 |
Data sheet Mikrotik CRS310-1G-5S-4S+IN
Switching results CRS310-1G-5S-4S+IN
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
|---|---|---|---|---|---|---|---|
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 3,738.6 | 45,401.8 | 10,808.3 | 44,270.7 | 10,808.3 | 35,047.6 |
| Switching | Non blocking Layer 2 capacity | 3,738.6 | 90,803.6 | 10,808.3 | 88,541.4 | 10,808.3 | 70,095.2 |
| Switching | Non blocking Layer 1 throughput | 3,738.6 | 46,000 | 10,808.3 | 46,000 | 10,808.3 | 46,000 |
| Switching | Non blocking Layer 1 capacity | 3,738.6 | 92,000 | 10,808.3 | 92,000 | 10,808.3 | 92,000 |
