Model	GS-6320-46S2C4XR
Hardware Specifications
100/1000X SFP/mini-GBIC Slots	48
10/100/1000T Copper Ports	2
10GBASE-LR/SR SFP+ Slots	4, compatible with 1000BASE-SX/LX/BX SFP
Console	1 x RJ45 serial port (115200 , 8, N, 1)
Reset Buton	< 5 sec: System reboot >= 10 sec: Factory default
Smart FAN	2
Power Requirements	AC: 100~240V, 50/60Hz DC: 36V-60V, 2A max. Redundant power designed
Power Consumption (Full Loading)	AC 110V: 72 watts/245BTU (max.) DC 60V: 69 watts/235BTU (max.)
ESD Protection	6KV DC
Dimensions (W x D x H)	440 x 200 x 44 mm, 1U height
Weight	3.4kg
SDRAM	512Mbytes
Flash Memory	64Mbytes
Switching Performance
Switch Fabric	176Gbps/non-blocking
Throughput	130Mpps@ 64Bytes packet
Switch Architecture	Store-and-Forward
Address Table	16K entries, automatic source address learning and aging
Shared Data Buffer	32M bits
Flow Control	IEEE 802.3x pause frame for full duplex Back pressure for half duplex
Jumbo Frame	10KB
Environments & Standards Conformance
Operating	Temperature: 0 ~ 50 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -10 ~ 70 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Regulatory Compliance	FCC Part 15 Class A, CE

Data sheet Planet GS-6320-46S2C4XR

Software Functions	Planet GS-6320-46S2C4XR L3 24-Port 10/100/1000T 802.3bt PoE + 2-Port 10GBEAS-T + 2-Port 10G SFP+ Managed Switch with Redundant Power
Layer 2 Functions
Port Configuration	Port disable/enable Auto-negotiation 10/100/1000Mbps full and half duplex mode selection Flow control disable/enable
Port Status	Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status
Port Mirroring	TX/RX/Both Many-to-1 monitor
VLAN	802.1Q tagged based VLAN, up to 255 VLAN groups Q-in-Q tunneling Private VLAN Edge (PVE) Port Isolation MAC-based VLAN IP Subnet-based VLAN Protocol-based VLAN VLAN Translation Voice VLAN MVR (Multicast VLAN Registration) GVRP Up to 255 VLAN groups, out of 4095 VLAN IDs
Link Aggregation	IEEE 802.3ad LACP/static trunk Supports 26 trunk groups with 16 ports per trunk
QoS	Traffic classification based, strict priority and WRR 8-level priority for switching: - Port number - 802.1p priority - 802.1Q VLAN tag - DSCP/ToS field in IP packet
IGMP Snooping	IPv4 IGMP (v1/v2/v3) snooping IPv4 IGMP querier mode support Supports 255 IGMP groups
MLD Snooping	IPv6 MLD (v1/v2) snooping IPv6 MLD querier mode support Supports 255 MLD groups
Access Control List	IP-based ACL/MAC-based ACL ACL based on: - MAC Address - IP Address - Ethertype - Protocol Type - VLAN ID - DSCP - 802.1p Priority Up to 256 entries
Bandwidth Control	Per port bandwidth control Ingress: 100Kbps~13000Mbps Egress: 100Kbps~13000Mbps
Layer 3 Functions
IP Interfaces	Max. 128 VLAN interfaces
Routing Table	Max. 128 routing entries
Routing Protocols	IPv4 OSPFv2 dynamic routing IPv4 hardware static routing IPv6 hardware static routing
Management
Basic Management Interfaces	Console; Telnet; Web browser; SNMP v1, v2c
Secure Management Interfaces	SSHv2, TLSv1.2, SNMP v3
Management Functions	Firmware upgrade by HTTP protocol through Ethernet network Remote syslog and local system log LLDP protocol UDLD NTP UPnP
