Mô tả sản phẩm

Planet XGS-6320-8UP4X là bộ chuyển mạch Ethernet 10Gbps quản lý Layer 3 được thiết kế cho nhu cầu băng thông cao cho thiết bị mạng tiên tiến, chẳng hạn như AP không dây Wi-Fi 6 / 6E, NAS, Server và những thiết bị có cáp quang hoặc đồng 10Gbps các giao diện. XGS-6320-12X4TR có 8 cổng PoE++ 10GBASE-T và 4 giao diện quang 10GBASE-X SFP + được thiết kế linh hoạt để mở rộng khoảng cách kết nối.

Planet XGS-6320-8UP4X có các tính năng:

8 cổng 10GBASE-T RJ45 tương thích với 100M/1G/2.5G/5GBASE-T và hỗ trợ chuẩn IEEE802.3bt PoE++
4 cổng 10GBASE-X SFP+, tương thích với mô-đun 1000/2500BASE-X SFP
Giao diện điều khiển RJ45 loại RS232
Tổng công suất PoE: 420 watt
Tính năng Layer 2: Hỗ trợ VLAN, Spanning Tree, Link Aggregation, LLDP, G.8032 ERPS
Tính năng Layer 3: Static Route và Dynamic Route (RIPv2, OSPFv2 và OSPFv3)
Quản lý chuyển đổi web, dòng lệnh Console / Telnet, chuyển mạch SNMP ,IPv4 và IPv6
Nguồn : 100 ~ 240V AC, 50 / 60Hz, tối đa 5A.

Thông số kỹ thuật

Model	XGS-6320-8UP4X
Hardware Specifications
Copper Ports	8 10GBASE-T RJ45 auto negotiation ports (Ports 5 to 12) Backward compatible with 10G/5G/2.5G/1G/100Mbps data rate
SFP+ Slots	4 10GBASE-SR/LR SFP+ ports (Ports 1 to 4) Backward compatible with 1000BASE-SX/LX/BX and 2500BASE-X SFP transceivers
PoE Injector Port	8 ports with 802.3bt PoE++ injector function from Ports 5 to 12
Console	1 x RJ45-to-DB9, RS232 serial port (115200, 8, N, 1)
Reset Button	< 5 sec: System reboot > 5 sec: Factory default
RAM	2,048Mbytes
Flash Memory	128Mbytes
Dimensions (W x D x H)	440 x 300 x 44mm, 1U height
Weight	4,285g
Power Requirements	100~240V AC, 50/60Hz, 5A max.
Power Consumption	33.4W / 114BTU (No loading) ; 488W / 1665.1BTU (Full loading)
ESD Protection	6KV DC
Surge Protection	4KV DC
Fan	3 smart fans
Switching Specifications
Switch Architecture	Store-and-Forward
Switch Fabric	240Gbps/non-blocking
Throughput	178.57 @ 64Bytes packet
Address Table	32K entries, automatic source address learning and aging
Shared Data Buffer	32Mbits
Flow Control	IEEE 802.3x pause frame for full duplex Back pressure for half duplex
Jumbo Frame	10Kbytes
Power over Ethernet
PoE Standard	IEEE 802.3bt PoE++ Type-4 PSE Backward compatible with 802.3at PoE+ PSE
PoE Power Supply Type	802.3bt End-span Mid-span Force
PoE Power Output	Per port 54V DC 802.3bt Type-4 mode: maximum 95 watts End-span mode: maximum 36 watts Mid-span mode: maximum 36 watts Force mode: maximum 95 watts
Power Pin Assignment	802.3bt: 1/2(-), 3/6(+),4/5(+), 7/8(-) End-span: 1/2(-), 3/6(+) Mid-span: 4/5(+), 7/8(-)
PoE Power Budget	420W maximum
Standards & Environment
Regulatory Compliance	FCC Part 15 Class A, CE
Operating	Temperature: 0 ~ 50 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -20 ~ 70 degrees C Relative Humidity: 5 ~ 95% (non-condensing)

Xem thêm

Thông số kỹ thuật

Data sheet Planet XGS-6320-8UP4X

Software Functions	XGS-6320-8UP4X Layer 3 8-Port 10GBASE-T 95W 802.3bt PoE + 4-Port 10GBASE-X SFP+ Managed Ethernet Switch
PoE Management Functions
Active PoE Device Detection	Yes
PoE Power Recycling	Yes, daily or predefined schedule
PoE Schedule	4 schedule profiles
PoE Extend Mode	Yes, max. 160 meters
PoE System Management	System PoE Admin control Total PoE power budget control Auto power input and PoE budget control PoE Legacy mode Over-temperature threshold alarm PoE usage threshold alarm
PoE Port Management	Port Enable/Disable/Schedule PoE mode control 802.3bt 802.3at End-span 802.3at Mid-span Force mode Port Priority
Layer 3 Functions
IP Interfaces	Max. 128 VLAN interfaces
Routing Table	Max. 512 static route entries Max. 3072 routing table entries
Routing Protocols	IPv4 RIPv2 IPv4 OSPFv2 IPv6 OSPFv3 IPv4 hardware static routing IPv6 hardware static routing
Layer 2 Function
Port Configuration	Port disable/enable Flow Control disable/enable Port link capability control
Port Status	Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status
Port Mirroring	TX/RX/Both Many-to-1 monitor RMirror – Remote Switched Port Analyzer (Cisco RSPAN) Supports up to 5 sessions
VLAN	IEEE 802.1Q tag-based VLAN, IEEE 802.1ad Q-in-Q tunneling Private VLAN Edge (PVE) MAC-based VLAN Protocol-based VLAN Voice VLAN MVR (Multicast VLAN Registration) GVRP Up to 4K VLAN groups, out of 4094 VLAN IDs
Spanning Tree Protocol	IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Supports 7 MSTP instances BPDU Guard, BPDU filtering and BPDU transparent Root Guard
Link Aggregation	IEEE 802.3ad LACP (static trunk) Supports 6 trunk groups with 12 ports per trunk
IGMP Snooping	IPv4 IGMP (v1/v2/v3) snooping IPv4 IGMP querier mode support Supports 255 IGMP groups
MLD Snooping	IPv6 MLD (v1/v2) snooping, IPv6 MLD querier mode support Supports 255 MLD groups
Bandwidth Control	Per port bandwidth control Ingress: 10Kbps~13128Mbps Egress: 10Kbps~13128Mbps
Ring	Supports ERPS, and complies with ITU-T G.8032 Recovery time < 10ms @ 3 nodes Recovery time <50ms @ 16 nodes Supports Major ring and sub-ring
Synchronization	IEEE 1588v2 PTP(Precision Time Protocol) Peer-to-peer transparent clock End-to-end transparent clock
QoS	Traffic classification based, strict priority and WRR 8-level priority for switching Port number 802.1p priority 802.1Q VLAN tag DSCP/TOS field in IP packet
Security Functions
Access Control List	IP-based ACL/MAC-based ACL ACL based on: MAC Address IP Address Ethertype Protocol Type VLAN ID DSCP 802.1p Priority Up to 512 entries
Security	Port security IP source guard, up to 512 entries Dynamic ARP inspection, up to 1K entries Command line authority control based on user level Static MAC address, up to 64 entries
AAA	RADIUS client TACACS+ client
Authentication	IEEE 802.1x port-based network access control MAC-based authentication Local/RADIUS authentication
Management Functions
Basic Management Interfaces	Console;Telnet; Web browser; SNMP v1, v2c
Secure Management Interfaces	SSHv2, TLSv1.2, SNMPv3
System Management	Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP Remote Syslog System log LLDP protocol NTP PLANET Smart Discovery Utility PLANET CloudViewerPro app
Event Management	Remote Syslog System log SMTP

Xem thêm thông số kỹ thuật

Bạn đang cần tư vấn về sản phẩm Planet XGS-6320-8UP4X

Vui lòng để lại số điện thoại hoặc lời nhắn, nhân viên sẽ liên hệ trả lời bạn sớm nhất

Đánh giá của bạn

Điểm 5/5 trên 1 đánh giá

Xem thêm các bình luận khác Ẩn bớt

Đang tải...

Sản phẩm cùng loại

Planet GS-2210-8P2S

Liên hệ

Planet GS-4210-8UP2S

Liên hệ

Planet MGS-6311-8P2X

Liên hệ

Software Functions	XGS-6320-8UP4X Layer 3 8-Port 10GBASE-T 95W 802.3bt PoE + 4-Port 10GBASE-X SFP+ Managed Ethernet Switch
PoE Management Functions
Active PoE Device Detection	Yes
PoE Power Recycling	Yes, daily or predefined schedule
PoE Schedule	4 schedule profiles
PoE Extend Mode	Yes, max. 160 meters
PoE System Management	System PoE Admin control Total PoE power budget control Auto power input and PoE budget control PoE Legacy mode Over-temperature threshold alarm PoE usage threshold alarm
PoE Port Management	Port Enable/Disable/Schedule PoE mode control 802.3bt 802.3at End-span 802.3at Mid-span Force mode Port Priority
Layer 3 Functions
IP Interfaces	Max. 128 VLAN interfaces
Routing Table	Max. 512 static route entries Max. 3072 routing table entries
Routing Protocols	IPv4 RIPv2 IPv4 OSPFv2 IPv6 OSPFv3 IPv4 hardware static routing IPv6 hardware static routing
Layer 2 Function
Port Configuration	Port disable/enable Flow Control disable/enable Port link capability control
Port Status	Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status
Port Mirroring	TX/RX/Both Many-to-1 monitor RMirror – Remote Switched Port Analyzer (Cisco RSPAN) Supports up to 5 sessions
VLAN	IEEE 802.1Q tag-based VLAN, IEEE 802.1ad Q-in-Q tunneling Private VLAN Edge (PVE) MAC-based VLAN Protocol-based VLAN Voice VLAN MVR (Multicast VLAN Registration) GVRP Up to 4K VLAN groups, out of 4094 VLAN IDs
Spanning Tree Protocol	IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Supports 7 MSTP instances BPDU Guard, BPDU filtering and BPDU transparent Root Guard
Link Aggregation	IEEE 802.3ad LACP (static trunk) Supports 6 trunk groups with 12 ports per trunk
IGMP Snooping	IPv4 IGMP (v1/v2/v3) snooping IPv4 IGMP querier mode support Supports 255 IGMP groups
MLD Snooping	IPv6 MLD (v1/v2) snooping, IPv6 MLD querier mode support Supports 255 MLD groups
Bandwidth Control	Per port bandwidth control Ingress: 10Kbps~13128Mbps Egress: 10Kbps~13128Mbps
Ring	Supports ERPS, and complies with ITU-T G.8032 Recovery time < 10ms @ 3 nodes Recovery time <50ms @ 16 nodes Supports Major ring and sub-ring
Synchronization	IEEE 1588v2 PTP(Precision Time Protocol) Peer-to-peer transparent clock End-to-end transparent clock
QoS	Traffic classification based, strict priority and WRR 8-level priority for switching Port number 802.1p priority 802.1Q VLAN tag DSCP/TOS field in IP packet
Security Functions
Access Control List	IP-based ACL/MAC-based ACL ACL based on: MAC Address IP Address Ethertype Protocol Type VLAN ID DSCP 802.1p Priority Up to 512 entries
Security	Port security IP source guard, up to 512 entries Dynamic ARP inspection, up to 1K entries Command line authority control based on user level Static MAC address, up to 64 entries
AAA	RADIUS client TACACS+ client
Authentication	IEEE 802.1x port-based network access control MAC-based authentication Local/RADIUS authentication
Management Functions
Basic Management Interfaces	Console;Telnet; Web browser; SNMP v1, v2c
Secure Management Interfaces	SSHv2, TLSv1.2, SNMPv3
System Management	Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP Remote Syslog System log LLDP protocol NTP PLANET Smart Discovery Utility PLANET CloudViewerPro app
Event Management	Remote Syslog System log SMTP

Software Functions

XGS-6320-8UP4X
Layer 3 8-Port 10GBASE-T 95W 802.3bt PoE + 4-Port 10GBASE-X SFP+ Managed Ethernet Switch

PoE Management Functions

Active PoE Device Detection

Yes

PoE Power Recycling

Yes, daily or predefined schedule

PoE Schedule

4 schedule profiles

PoE Extend Mode

Yes, max. 160 meters

PoE System Management

System PoE Admin control
Total PoE power budget control
Auto power input and PoE budget control
PoE Legacy mode
Over-temperature threshold alarm
PoE usage threshold alarm

PoE Port Management

Port Enable/Disable/Schedule
PoE mode control
   802.3bt
   802.3at End-span
   802.3at Mid-span
   Force mode
Port Priority

Layer 3 Functions

IP Interfaces

Max. 128 VLAN interfaces

Routing Table

Max. 512 static route entries
Max. 3072 routing table entries

Routing Protocols

IPv4 RIPv2
IPv4 OSPFv2
IPv6 OSPFv3
IPv4 hardware static routing
IPv6 hardware static routing

Layer 2 Function

Port Configuration

Port disable/enable
Flow Control disable/enable
Port link capability control

Port Status

Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status

Port Mirroring

TX/RX/Both
Many-to-1 monitor
RMirror – Remote Switched Port Analyzer (Cisco RSPAN)
Supports up to 5 sessions

VLAN

IEEE 802.1Q tag-based VLAN,
IEEE 802.1ad Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
GVRP
Up to 4K VLAN groups, out of 4094 VLAN IDs

Spanning Tree Protocol

IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
Supports 7 MSTP instances
BPDU Guard, BPDU filtering and BPDU transparent
Root Guard

Link Aggregation

IEEE 802.3ad LACP (static trunk)
Supports 6 trunk groups with 12 ports per trunk

IGMP Snooping

IPv4 IGMP (v1/v2/v3) snooping
IPv4 IGMP querier mode support
Supports 255 IGMP groups

MLD Snooping

IPv6 MLD (v1/v2) snooping,
IPv6 MLD querier mode support
Supports 255 MLD groups

Bandwidth Control

Per port bandwidth control
Ingress: 10Kbps~13128Mbps
Egress: 10Kbps~13128Mbps

Ring

Supports ERPS, and complies with ITU-T G.8032
Recovery time < 10ms @ 3 nodes
Recovery time <50ms @ 16 nodes
Supports Major ring and sub-ring

Synchronization

IEEE 1588v2 PTP(Precision Time Protocol)
Peer-to-peer transparent clock
End-to-end transparent clock

QoS

Traffic classification based, strict priority and WRR
8-level priority for switching
   Port number
   802.1p priority
   802.1Q VLAN tag
   DSCP/TOS field in IP packet

Security Functions

Access Control List

IP-based ACL/MAC-based ACL
ACL based on:
   MAC Address
   IP Address
   Ethertype
   Protocol Type
   VLAN ID
   DSCP
   802.1p Priority
Up to 512 entries

Security

Port security
IP source guard, up to 512 entries
Dynamic ARP inspection, up to 1K entries
Command line authority control based on user level
Static MAC address, up to 64 entries

AAA

RADIUS client
TACACS+ client

Authentication

IEEE 802.1x port-based network access control
MAC-based authentication
Local/RADIUS authentication

Management Functions

Basic Management Interfaces

Console;Telnet; Web browser; SNMP v1, v2c

Secure Management Interfaces

SSHv2, TLSv1.2, SNMPv3

System Management

Firmware upgrade by HTTP protocol through Ethernet network
Configuration upload/download through HTTP
Remote Syslog
System log
LLDP protocol
NTP
PLANET Smart Discovery Utility
PLANET CloudViewerPro app

Event Management

Remote Syslog
System log
SMTP

Software Functions	XGS-6320-8UP4X Layer 3 8-Port 10GBASE-T 95W 802.3bt PoE + 4-Port 10GBASE-X SFP+ Managed Ethernet Switch
PoE Management Functions
Active PoE Device Detection	Yes
PoE Power Recycling	Yes, daily or predefined schedule
PoE Schedule	4 schedule profiles
PoE Extend Mode	Yes, max. 160 meters
PoE System Management	System PoE Admin control Total PoE power budget control Auto power input and PoE budget control PoE Legacy mode Over-temperature threshold alarm PoE usage threshold alarm
PoE Port Management	Port Enable/Disable/Schedule PoE mode control 802.3bt 802.3at End-span 802.3at Mid-span Force mode Port Priority
Layer 3 Functions
IP Interfaces	Max. 128 VLAN interfaces
Routing Table	Max. 512 static route entries Max. 3072 routing table entries
Routing Protocols	IPv4 RIPv2 IPv4 OSPFv2 IPv6 OSPFv3 IPv4 hardware static routing IPv6 hardware static routing
Layer 2 Function
Port Configuration	Port disable/enable Flow Control disable/enable Port link capability control
Port Status	Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status
Port Mirroring	TX/RX/Both Many-to-1 monitor RMirror – Remote Switched Port Analyzer (Cisco RSPAN) Supports up to 5 sessions
VLAN	IEEE 802.1Q tag-based VLAN, IEEE 802.1ad Q-in-Q tunneling Private VLAN Edge (PVE) MAC-based VLAN Protocol-based VLAN Voice VLAN MVR (Multicast VLAN Registration) GVRP Up to 4K VLAN groups, out of 4094 VLAN IDs
Spanning Tree Protocol	IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Supports 7 MSTP instances BPDU Guard, BPDU filtering and BPDU transparent Root Guard
Link Aggregation	IEEE 802.3ad LACP (static trunk) Supports 6 trunk groups with 12 ports per trunk
IGMP Snooping	IPv4 IGMP (v1/v2/v3) snooping IPv4 IGMP querier mode support Supports 255 IGMP groups
MLD Snooping	IPv6 MLD (v1/v2) snooping, IPv6 MLD querier mode support Supports 255 MLD groups
Bandwidth Control	Per port bandwidth control Ingress: 10Kbps~13128Mbps Egress: 10Kbps~13128Mbps
Ring	Supports ERPS, and complies with ITU-T G.8032 Recovery time < 10ms @ 3 nodes Recovery time <50ms @ 16 nodes Supports Major ring and sub-ring
Synchronization	IEEE 1588v2 PTP(Precision Time Protocol) Peer-to-peer transparent clock End-to-end transparent clock
QoS	Traffic classification based, strict priority and WRR 8-level priority for switching Port number 802.1p priority 802.1Q VLAN tag DSCP/TOS field in IP packet
Security Functions
Access Control List	IP-based ACL/MAC-based ACL ACL based on: MAC Address IP Address Ethertype Protocol Type VLAN ID DSCP 802.1p Priority Up to 512 entries
Security	Port security IP source guard, up to 512 entries Dynamic ARP inspection, up to 1K entries Command line authority control based on user level Static MAC address, up to 64 entries
AAA	RADIUS client TACACS+ client
Authentication	IEEE 802.1x port-based network access control MAC-based authentication Local/RADIUS authentication
Management Functions
Basic Management Interfaces	Console;Telnet; Web browser; SNMP v1, v2c
Secure Management Interfaces	SSHv2, TLSv1.2, SNMPv3
System Management	Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP Remote Syslog System log LLDP protocol NTP PLANET Smart Discovery Utility PLANET CloudViewerPro app
Event Management	Remote Syslog System log SMTP

Software Functions

XGS-6320-8UP4X
Layer 3 8-Port 10GBASE-T 95W 802.3bt PoE + 4-Port 10GBASE-X SFP+ Managed Ethernet Switch

PoE Management Functions

Active PoE Device Detection

Yes

PoE Power Recycling

Yes, daily or predefined schedule

PoE Schedule

4 schedule profiles

PoE Extend Mode

Yes, max. 160 meters

PoE System Management

System PoE Admin control
Total PoE power budget control
Auto power input and PoE budget control
PoE Legacy mode
Over-temperature threshold alarm
PoE usage threshold alarm

PoE Port Management

Port Enable/Disable/Schedule
PoE mode control
   802.3bt
   802.3at End-span
   802.3at Mid-span
   Force mode
Port Priority

Layer 3 Functions

IP Interfaces

Max. 128 VLAN interfaces

Routing Table

Max. 512 static route entries
Max. 3072 routing table entries

Routing Protocols

IPv4 RIPv2
IPv4 OSPFv2
IPv6 OSPFv3
IPv4 hardware static routing
IPv6 hardware static routing

Layer 2 Function

Port Configuration

Port disable/enable
Flow Control disable/enable
Port link capability control

Port Status

Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status

Port Mirroring

TX/RX/Both
Many-to-1 monitor
RMirror – Remote Switched Port Analyzer (Cisco RSPAN)
Supports up to 5 sessions

VLAN

Spanning Tree Protocol

Link Aggregation

IEEE 802.3ad LACP (static trunk)
Supports 6 trunk groups with 12 ports per trunk

IGMP Snooping

IPv4 IGMP (v1/v2/v3) snooping
IPv4 IGMP querier mode support
Supports 255 IGMP groups

MLD Snooping

IPv6 MLD (v1/v2) snooping,
IPv6 MLD querier mode support
Supports 255 MLD groups

Bandwidth Control

Per port bandwidth control
Ingress: 10Kbps~13128Mbps
Egress: 10Kbps~13128Mbps

Ring

Supports ERPS, and complies with ITU-T G.8032
Recovery time < 10ms @ 3 nodes
Recovery time <50ms @ 16 nodes
Supports Major ring and sub-ring

Synchronization

IEEE 1588v2 PTP(Precision Time Protocol)
Peer-to-peer transparent clock
End-to-end transparent clock

QoS

Traffic classification based, strict priority and WRR
8-level priority for switching
   Port number
   802.1p priority
   802.1Q VLAN tag
   DSCP/TOS field in IP packet

Security Functions

Access Control List

IP-based ACL/MAC-based ACL
ACL based on:
   MAC Address
   IP Address
   Ethertype
   Protocol Type
   VLAN ID
   DSCP
   802.1p Priority
Up to 512 entries

Security

Port security
IP source guard, up to 512 entries
Dynamic ARP inspection, up to 1K entries
Command line authority control based on user level
Static MAC address, up to 64 entries

AAA

RADIUS client
TACACS+ client

Authentication

IEEE 802.1x port-based network access control
MAC-based authentication
Local/RADIUS authentication

Management Functions

Basic Management Interfaces

Console;Telnet; Web browser; SNMP v1, v2c

Secure Management Interfaces

SSHv2, TLSv1.2, SNMPv3

System Management

Event Management

Remote Syslog
System log
SMTP

Hỗ trợ trực tuyến

Tư vấn

Kinh doanh

Kỹ thuật

Planet GS-2210-8P2S

Planet GS-4210-8UP2S

Planet MGS-6311-8P2X

Thông số kỹ thuật

Chính sách bán hàng

Yêu cầu Báo giá

Planet XGS-6320-8UP4X

CÔNG TY TNHH TM KỸ THUẬT THẾ GIỚI MẠNG
