SonicWall NSA 4700 (02-SSC-4328)

02-SSC-4328 - Tường lửa Firewall SonicWall NSA 4700: ● 6 x 10G/5G/2.5G/1G (SFP+); 24 x 1GbE Cu, 2 USB 3.0, 1 Console, 1 Management port ● Firewall inspection throughput : 18 Gbps ● Application inspection throughput : 11 Gbps ● IPS throughput : 10 Gbps ● Threat Prevention throughput : 9.5 Gbps ● IPSec VPN throughput : 11 Gbps ● Maximum Connections : 4,000,000 ● Storage : 128 GB ● SonicOS 7.0
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị tường lửa Firewall SonicWall NSA 4700 (02-SSC-4328)

Model SonicWall NSA 4700 (02-SSC-4328)
Operating system SonicOS 7.0
Interfaces 6 x 10G/5G/2.5G/1G (SFP+); 24 x 1GbE Cu, 2 USB 3.0, 1 Console, 1 Management port
Storage 128GB
Expansion Storage Expansion Slot (Up to 1TB)
VLAN interfaces 512
Access points supported (maximum) 512
Firewall/VPN Performance
Firewall inspection throughput 18 Gbps
Threat Prevention throughput 9.5 Gbps
Application inspection throughput 11 Gbps
IPS throughput 10 Gbps
Anti-malware inspection throughput 9.5 Gbps
TLS/SSL inspection and decryption throughput (DPI SSL) 5 Gbps
IPSec VPN throughput 11 Gbps
Connections per second 115000
Maximum Connections (SPI) 4000000
MAX DPI-SSL Connections 350000
Maximum connections (DPI) 2000000
VPN
Site-to-site VPN tunnels 4000
IPSec VPN clients (max) 500 (3000)
SSL VPN licenses (max) 2 (1000)
Encryption/Authentication DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN RIP, OSPF, BGP
Certificate support Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10
NetExtender Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded)
Security services
Deep Packet Inspection services Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service Supported
Application Visualization Yes
Application Control Yes
Capture Advanced Threat Protection Yes
Networking
IP address assignment Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols BGP4, OSPF, RIPv1/v2, static routes, policy-based routing
QoS Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
Local user database 2500
VoIP Full H323-v1-5, SIP
Standards TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications (pending) FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS)
Common Access Card (CAC) Supported
High availability Active/Passive with stateful synchronization
Hardware
Form factor 1U Rack Mountable
Fans 2 (removable)
Power supply 1x350W
Maximum power consumption (W) 135.8
Input power 100-240 VAC, 50-60 Hz
Total heat dissipation 463.1
Dimensions 43 x 46.5 x 4.5 (cm) 16.9 x 18.1 x 1.8 in
Weight 7.8 Kg
WEEE weight 9.6 Kg
Shipping weight 13.5 Kg
Environment (Operating/Storage) 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity 0-90% R.H non-condensing

02-SSC-4328 : SonicWall NSA 4700 Hardware

  • Recommended for 1001 - 2500 User Network
  • Threat Prevention Throughput: 9.5 Gbps
  • Site-to-Site VPN Tunnels: 4,000
  • Concurrent Sessions: 4,000,000

Data sheet SonicWall Gen 7 NSa Series
