Thiết bị tường lửa Firewall SonicWall NSsp 13700
| Model | NSsp 13700 |
| Operating System | SonicOS 7.0.1 |
| Interfaces | 2x100/40-GbE QSFP28, 8x25/10/5/2.5-GbE SFP28, 4x10/5/2.5-GbE SFP+, 4x10/5/2.5/1-GbE Cu, 16x1-GbE 2 USB 3.0, 1 Console, 1 Mgmt. port |
| Total storage | 1.5TB |
| Management | CLI, SSH, Web UI, REST APIs |
| SSO Users | 100,000 |
| Access points supported (maximum) | 512 |
| Logging | Analyzer, Local Log, Syslog, IPFIX, NetFlow |
| Firewall/VPN Performance | |
| Firewall inspection throughput | 60 Gbps |
| Threat Prevention throughput | 45.5 Gbps |
| Application inspection throughput | 57 Gbps |
| IPS throughput | 48 Gbps |
| TLS/SSL inspection and decryption throughput (DPI SSL) | 16.5 Gbps |
| VPN throughput | 29 Gbps |
| Connections per second | 280,000 |
| Maximum connections (SPI) | 25,000,000 |
| Maximum connections (DPI) | 22,000,000 |
| Maximum connections (DPI SSL) | 2,000,000 |
| VPN | |
| Site-to-site VPN tunnels | 12,000 |
| IPSec VPN clients (max) | 2,000 (6,000) |
| SSL VPN licenses (max) | 2 (3000) |
| Encryption/authentication | DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography |
| Key exchange | Diffie Hellman Groups 1, 2, 5, 14v |
| Route-based VPN | RIP, OSPF, BGP |
| Certificate support | Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP |
| VPN features | Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN |
| Global VPN client platforms supported | Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10 |
| NetExtender | Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE |
| Mobile Connect | Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Chrome, Windows 8.1 (Embedded) |
| Networking | |
| Multi-Instance Firewall | N/A |
| IP address assignment | Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay |
| NAT modes | 1:1, many:1, 1:many, flexible NAT (overlapping IP), PAT, transparent mode |
| Logical VLAN and tunnel interfaces (maximum) | 1024 |
| Wire Mode | – |
| Routing protocols | BGP4, OSPF, RIPv1/ v2, static routes, policy-based routing |
| QoS | Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM) |
| Authentication | LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC) |
| Local user database | 4,000 |
| VoIP | Full H323-v1-5, SIP |
| Standards | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
| Certifications (in progress) | FIPS 140-2 (with Suite B) Level 2, UC APL, VPNC, IPv6 (Phase 2), ICSA Network Firewall, ICSA Anti-virus, Common Criteria NDPP (Firewall and IPS) |
| High availability | Active/Passive with stateful synchronization |
| Hardware | |
| Power supply | 2x350W |
| Fans | 3 (removable) |
| Redundant Power Supply | 100-240 VAC, 50-60 Hz |
| Maximum power consumption (W) | 181.2 |
| Total heat dissipation | 617.89 BTU |
| Form factor | 1U Rack Mountable |
| Dimensions | 43 x 32.5 x 4.5 (cm) |
| Weight | 9.1 Kg |
| WEEE weight | 11 Kg |
| Shipping weight | 14.9 Kg |
| Environment (Operating/Storage) | 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C) |
| Humidity | 0-90% R.H non-condensing |
