Bộ lưu điện True Online Sorotec HP2116C 3KT :
Bộ lưu điện True Online Sorotec HP2116C 3KT
| Model | HP2116C 3KT |
| POWER | |
| Capacity | • 3KVA/2.7KW |
| Power Factor | • 0.9 PF (1.0 Option) |
| System Efficiency | • Battery mode 94%. ECO mode 98%. |
| Auto restart | • UPS auto shutdow when battery low, and auto restart when AC recovery |
| INPUT | |
| Voltage range | • 220VAC (115V~300V) |
| Frequency | • 40~70Hz auto sensing. |
| Current | • 15A |
| Power Factor | • > 0,98 |
| THDI | • < 10% |
| Phase | • Single phase with ground |
| OUTPUT | |
| Voltage | • 220VAC±1% |
| Frequency | • 50Hz/60Hz±0.5Hz auto sensing. |
| Wave form | • Pure Sine Wave. |
| Technology | • True Online Double Conversion |
| Transfer Time | • 0 mili second. Bypass to Inverter and vice versa <4ms |
| Distortion full load | • Linear load <3%, Non-linear load < 6% |
| Crest Ratio | • 3:1 (max) |
| BATTERY | |
| Battery type | • CSB Sealed Lead Acid Battery, design 5 years. Maintenance free. |
| Capacity battery | • 12V9Ah*6 |
| Charger time | • 5 hours to 90% capacity |
| BACKUP TIME | |
| 25% Load | • 15 minutes |
| 50% Load | • 8 minutes |
| 75% Load | • 4 minutes |
| 100% Load | • 3 minutes |
| Overload | • 110% warning, 130% bypass in 60 seconds |
| SAFETY | |
| Certification | • CE(EN60950), IEC 61000-4-2 (ESD) Level 4, IEC 61000-4-3 (RS) Level 3, IEC 61000-4-2 (EFT) Level 4, IEC 61000-4-5 (Surge) Level 4 |
| EMI | • EN62040-2 Class A, EN55022 / IEC62040-2 Class B |
| Protection | • Anti-pulses, noise filters, low Voltage, Over voltage, Overload, Short circuit, overheating… |
| MAINTENCE | |
| Bypass Maintenance | • N/A |
| Auto Bypass | • UPS Fault, Overload, battery low |
| COMMUNICATION INTERFACE | |
| Control Panel | • On/Off, LCD Display |
| LCD display | • AC mode, Bypass mode, Inverter mode, Input Voltage, Output Voltage, Frequency, Load, Capacity battery….. |
| Smart Slot | • RS232/USB, SMNP Slot, RJ45 protec dataline…Options: WebPower, AS400 Card, USB card or WinPower CMC) |
| Function N+X | • N/A |
| Softwave | • Power Manager allows monitoring, automatic control on/off UPS and system. |
| ENVIRONMENT | |
| Temperature working | • 0℃~40℃ Humidity 20%~90% non-condensing. |
| Noise | • 45Db |
| PHYSICAL | |
| UPS W*D*H(mm) | • 400*190*320 (24.5 kg) |
| Package size UPS (mm) | • 493*285*430 (26.5 kg) |
