Bộ lưu điện Sorotec POWER 5.5 Auto Rescue Elevator :
Bộ lưu điện Sorotec POWER 5.5 Auto Rescue Elevator
| Model | POWER 5.5 |
| POWER | |
| Capacity | 550 kg |
| Power factor | 0.8 PF |
| System efficiency | AC mode 98% |
| Auto restart | UPS auto shutdow when battery low, and auto restart when AC recovery |
| INPUT | |
| Voltage range | 220VAC (145V~275V) |
| Frequency | 50/60Hz (46~64) auto sensing. |
| Phase | Single phase with ground (N-L-G) |
| Current | 7A |
| OUTPUT | |
| Voltage | 220VAC±2% |
| Frequency | 50Hz/60Hz±0.5Hz auto sensing. |
| Wave form | Pure Sine Wave. |
| Technology | Line interactive online |
| Transfer Time | 2~6 ms (Max 10ms) |
| Distortion full load | Linear load <3%, Non-linear load < 6%. |
| Crest Ratio | 3:1 (max) |
| BATTERY | |
| Battery type | Sealed Lead Acid Battery, design 5 years. Maintenance free. |
| Capacity battery | 12V-9AH*2 |
| Charger time | 4 hours to 90% capacity, fast charger |
| Overload | 120% UPS auto adj value output voltage down , UPS shutdown in 5 seconds |
| SAFETY | |
| Certification | CE(EN60950), IEC 61000-4-2 (ESD) Level 4, IEC 61000-4-3 (RS) Level 3, IEC 61000-4-2 (EFT) Level 4, IEC 61000-4-5 (Surge) Level 4 |
| EMI | EN62040-2 Class A, EN55022 / IEC62040-2 Class B |
| Protection | Low Voltage, Over voltage, Overload, Short circuit..battery discharge protection. |
| COMMUNICATION INTERFACE | |
| Control Panel | On/Off, LCD Display |
| LCD | Display AC mode, Bypass mode, Inverter mode, Input Voltage, Output Voltage, Frequency, Load, Capacity battery….. |
| ENVIRONMENT | |
| Temperature working | 0oC~40oC, Humidity 20%~90% non-condensing. |
| Noise | 45Db |
| Fan | Smart Fan temperature sensor |
| PHYSICAL | |
| UPS W*D*H (mm) | 370*125*190 (12.5 Kg) |
| Package size | 440*195*280 (13 Kg) |
