Mô tả sản phẩm

Thiết bị mạng Switch Trendnet TI-G162

Model	TI-G162
Device Interface	14 x Gigabit ports 2 x Gigabit SFP slots 6-pin removable terminal block LED indicators DIN-Rail mount Wall mount Grounding point
Data Transfer Rate	Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Gigabit: 2000Mbps (full duplex) SFP: 2000Mbps (full duplex)
Performance	Data RAM Buffer: 512KB Switching Fabric: 32Gbps MAC Address Table: 8K entries Jumbo Frame: 9KB Forwarding rate: 23.8Mpps (64-byte packet size)
Special Features	Hardened components rated for extreme temperatures Multiple power inputs ESD contact 6kV, air 8kV, and surge 2kV support Low-profile design
DC Power	Input: 12 – 56V DC Recommended power supply: TI-M6024 (sold separately) Max. consumption: 13W
Optional Power Adapter (48VDC3000 sold separately)	Input: 100 – 240V AC, 50/60Hz, 2A Output: 48V DC, 3.34A 160W max.
Terminal Block	Redundant power inputs, alarm relay contact, 6 pin Wire range: 0.34mm^2 to 2.5mm^2 Solid wire (AWG): 12-24/14-22 Stranded wire (AWG): 12-24/14-22 Torque: 5 lb. – In / 0.5Nm / 0.56Nm Wire strip length: 7-8mm
Alarm Relay Contact	Relay outputs with current carrying capacity of 1A, 24V DC Open circuit mode when two power sources are connected Short circuit mode when only one power source is connected
MTBF	514,167 hrs @ 50° C 188,310 hrs @ 75° C
Housing	IP30 metal case DIN-Rail mount Wall mount Grounding point 6kV contact protection 8kV air protection 2kV surge protection
Operating Temperature	- 40° – 75° C (-40° – 167° F)
Operating Humidity	Max. 95% non-condensing
Dimensions (L x W x H)	155 x 120 x 48mm (6 x 4.7 x 1.9 in.)
Weight	536g (18.9 oz.)
Certifications	CE FCC MET Shock (IEC 60068-2-27) Freefall (IEC 60068-2-32) Vibration (IEC 60068-2-6)
