Synology SA3200D

Thiết bị NAS Synology SA3200D: Simplify and centralize your data management infrastructure with Synology SA3200D. - High Availability: Dual storage controllers. - Cost-effective: Shared storage design. - Effortless: Automatic system-level protection. - Scalable: Up to 36 drives for 576 TB
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng

Thiết bị NAS Synology SA3200D


Number of Controller Module 2


CPU Model Intel Xeon D-1521
CPU Quantity 1 (per controller)
CPU Architecture 64-bit
CPU Frequency 4-core 2.4 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine


System Memory 8 GB DDR4 ECC UDIMM (per controller)
Memory Module Pre-installed 8 GB (8 GB x 1) (per controller)
Total Memory Slots 4 (per controller)
Maximum Memory Capacity 64 GB (16 GB x 4) (per controller)


Drive Bays 12
Maximum Drive Bays
with Expansion Unit
36 (RXD1219sas x 2)
Compatible Drive Type
  • 3.5" SAS HDD
  • 2.5" SAS HDD
  • 2.5" SAS SSD
Maximum Internal Raw Capacity 192 TB (16 TB drive x 12) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 576 TB (192 TB + 16 TB drive x 24) (Capacity may vary by RAID types)
Maximum Single Volume Size*
  • 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
Hot Swappable Drive

External Ports

RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support) (per controller)
RJ-45 10GbE LAN Port 1 (per controller)
Expansion Port 1


PCIe Expansion 1 x Gen3 x8 slot (x8 link) (per controller)
Add-In-Card Support PCIe Network Interface Card

File System

Internal Drives
  • Btrfs
  • EXT4


Form Factor (RU) 2U
Size (Height x Width x Depth) 88 mm x 482 mm x 724 mm
Weight 19.7 kg
Rack Installation Support* 4-post 19" rack


System Fan 60 mm x 60 mm x 2 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Power Recovery
Noise Level* 51.3 dB(A)
Power Supply Unit / Adapter 500 W
Redundant Power Supply
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption 417.48 W (Access)
274.38 W (HDD Hibernation)


Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)


5 Years
