WiFi Planet WDAP-C7210E

Thiết bị phát WiFi Planet WDAP-C7210E - 1200Mbps 802.11ac Wave 2 Dual Band Ceiling-mount Wireless Access Point w/802.3at PoE+ and 2x 10/100/1000T LAN Ports ● Fast Roaming with 802.11k, 802.11v, and 802.11r ● Operation modes: AP, Gateway, WISP, Repeater, Super WDS.
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị phát WiFi Outdoor Planet WDAP-C7210E

Model WDAP-C7210E
Hardware Specifications
Interfaces LAN
 ● 2 x 10/100/1000BASE-T RJ45 port
 ● Auto-negotiation and auto MDI/MDI-X
Antennas Gain: 4 x Internal 5dBi antenna (2.4G x2, 5G x2)
Reset Button Reset button on the rear side (Press over 15 seconds to reset the device to factory default)
Dimensions (W x D x H) 186 x 186 x 35.8 mm
Weight 380 ± 5g
Power Requirements 48V DC IN, 0.5A, IEEE 802.3at PoE+ or
12V DC IN, 1.5A from DC Jack ( 5.5 x 2.1mm )
Power Consumption < 12W
Mounting Ceiling mount
Wireless Interface Specifications
Standard IEEE 802.11ac
IEEE 802.11n
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x flow control
IEEE 802.11k, 802.11v, and 802.11r
Media Access Control CSMA / CA
Data Modulation 802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
Band Mode 2.4G / 5G concurrent mode
Frequency Range 2.4GHz:
※ FCC: 2.412~2.462GHz
※ ETSI: 2.412~2.472GHz

5GHz:
※ FCC: 5.180~5.240GHz, 5.745~5.825GHz
※ ETSI: 5.180~5.700GHz
Operating Channels FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 channels)
ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 channels)
5GHz channel list will vary in different countries according to their regulations.
Max. Transmit Power (dBm) FCC: up to 22 ± 1dBm
ETSI: < 20dBm (EIRP)
Environment & Certification
Temperature Operating: 0 ~ 40 degrees C
Storage: -40 ~ 70 degrees C
Humidity Operating: 10 ~ 90% (non-condensing)
Storage: 5 ~ 95% (non-condensing)
Regulatory CE, RoHS

Data sheet Planet WDAP-C7210E

Extremely High Speed and Dual Band Make Wi-Fi Transmission More Powerful

Software Features
LAN Static IP/DHCP Client
Supports IP-MAC binding
WAN Type
(GW/WISP mode)
Static IP
Dynamic IP
PPPoE
Wireless Mode
Access Point
Gateway
WISP
Repeater
Super WDS
Channel Width 20MHz, 40MHz, 80MHz
Encryption Security 64-/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1X
Wireless Security Enable/Disable SSID Broadcast
Wireless max. 32 MAC addresses filtering
User Isolation
Max. SSIDs 8 (4 per radio)
Max. Clients 64 per radio (50 is suggested, depending on usage)
Max. WDS Peers 4
Wireless QoS Supports Wi-Fi Multimedia (WMM)
Wireless Advanced Auto channel selection
5-level Transmit Power Control (Max. (100%), Efficient (75%), Enhanced (50%), Standard (25%), Min. (12.5%))
Client Limit Control, Coverage Threshold
Wi-Fi channel analysis chart
Fast Roaming
Status Monitoring Device status, wireless client list
PLANET Smart Discovery
DHCP client table
System Log supports remote syslog server
VLAN IEEE 802.1Q VLAN (VID: 3~4094)
SSID-to-VLAN mapping to up to 4 SSIDs
Self-healing Supports auto reboot settings per day/hour
Management Remote management through PLANET DDNS/Easy DDNS
Configuration backup and restoration
Supports UPnP
Supports IGMP Proxy
Supports PPTP/L2TP/IPSec VPN Pass-through
SNMP v1/v2c/v3 support, MIB I/II, Private MIB
Central Management Applicable controllers: NMS-500, NMS-1000V
*Remarks: The feature will be supported through firmware/system upgrade.
