Model	NXC2500
Port Density
10/100/1000 Mbps LAN ports	6
USB port	2
Performance
Throughput (Gbps)	1
Managed AP number (default/max.)	8/64
Fanless	Yes
WLAN Features
Wireless security (WPA/WPA2-PSK, Enterprise)	Yes
Dynamic channel selection	Yes
Wireless multicast setting	Yes
AP load balancing	Yes
AP planning and site-survey	Yes (AP planning and coverage detection)
ZyMesh	Licensed service
Band select	Yes
Client signal threshold	Yes
Auto healing	Yes
Fast roaming	Pre-authentication, PMK caching and 802.11r/k/v
Security Features
IEEE 802.1X	Yes
IEEE 802.11w	Yes
Layer-2 isolation	Yes
Web authentication	Yes
MAC filtering	Yes
RADIUS authentication	Yes
Microsoft AD authentication	Yes
LDAP authentication	Yes
Embedded RADIUS server	Yes (512 user)
Rogue AP detection	Yes
Identity-based user security management	Yes
Wireless intrusion detection	Rogue AP detection and containment
Control and Provisioning
Managed AP discovery	Broadcast/DHCP option/DNS/Manual
CAPWAP	Yes
AP data forwarding mode support	Distributed (local bridge) and Centralized (data tunnel)
Management interface	HTTP/HTTPS/Telnet/SSH/SNMP
Output power control	Yes
Wire/wireless packet capture	Yes
Network
VLANs	Yes
DHCP client	Yes
DHCP relay, server	Yes
NAT	Yes
Static routing	256
Policy routing	256
Access Control
MAC filter list	Yes
MAC authentication	Internal and external RADIUS
Guest account generator	Yes (512 user)
Customizable web login portal	Yes
QoS
WMM/power save	Yes
DiffServ marking	Yes
AP load balancing	Yes
Management Features
CLI with SSH	Yes
Web UI with SSL	Yes
myZyXEL.com 2.0	Yes
SNMP	v1, v2c, v3
Multi-level administration roles	Admin, Limited Admin and Guest Manager
ZyXEL One Network
ZON Utility	• Discovery of ZyXEL switches, APs, WLAN controllers and gateways • Centralized and batch configurations ■ IP configuration ■ IP renew ■ Device reboot ■ Device factory reset ■ Device locating ■ Web GUI access ■ Firmware upgrade ■ Password configuration ■ One-click quick association with ZyXEL AP Configurator (ZAC)
User/Application Management
Authentication	RADIUS/Microsoft AD/LDAP/Local
Local user database	Yes (512)
User/group policy	Yes
Authentication by QR code	Yes
Captive portal	Yes
External portal page	Yes
Page upload	Yes
Other
System diagnostic tool	Yes
ZyXEL Wireless Optimizer	Supported
Certification
EMC	• FCC Part 15B • CE EN55022, EN55024 • ERP Lot 6 • C-tick AS/NZSCISPR22 • BSMI CNS13438
Safety	• LVD EN60950-1: A12 • BSMI CNS14336
Power Requirements
Power supply	12 VDC, 100 - 240 VAC
Max. power consumption (watt)	10.57
Physical Specifications
Item Dimensions (WxDxH)(mm/in.)	242.0 x 175.39 x 35.5/9.53 x 6.9 x 1.4
Item Weight (kg/lb.)	1.254/2.76
Packing Dimensions (WxDxH)(mm/in.)	395 x 238 x 101/15.55 x 9.37 x 3.98
Packing Weight (kg/lb.)	2.49/5.49
Included accessories	• Power adapter • Rack mounting kit
Environmental Specifications
Operating Temperature	0°C to 40°C/32°F to 104°F
Operating Humidity	5% to 95% (non-condensing)
Storage Temperature	-20°C to 70°C/-4°F to 158°F
Storage Humidity	5% to 95% (non-condensing)
MTBF (hr)	815,464
