Cisco C1000-48T-4X-L

Cisco C1000-48T-4X-L Catalyst 1000 48 port GE, 4x10G SFP

  • 48x 10/100/1000 Ethernet ports
  • 4x 10G SFP uplinks
  • Weight 3.95 kg
  • Over-the-air Bluetooth access
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị chuyển mạch 48 ports data Cisco C1000-48T-4X-L

Model

C1000-48T-4X-L

Hardware
Interface 48x 10/100/1000 Ethernet ports, 4x 10G SFP uplinks
Console ports
  • 1x RJ-45 Ethernet
  • USB mini-B
  • USB-A port for storage and Bluetooth console
Fanless No
Dimensions (WxDxH in inches) 17.5 x 10.73 x 1.73
Weight (kg) 3.95

Memory and processor

CPU

ARM v7 800 MHz

DRAM

512 MB

Flash memory

256 MB

Performance

Forwarding bandwidth

88 Gbps

Switching bandwidth

176 Gbps

Forwarding rate (64‑byte L3 packets)

77.38 Mpps

Unicast MAC addresses

16,000

IPv4 unicast direct routes

542

IPv4 unicast indirect routes

256

IPv6 unicast direct routes

414

IPv6 unicast indirect routes

128

IPv4 multicast routes and IGMP groups

1024

IPv6 multicast groups

1024

IPv4/MAC security ACEs

600

IPv6 security ACEs

600

Maximum active VLANs

256

VLAN IDs available

4094

Maximum STP instances

64

Maximum SPAN sessions 4
MTU-L3 packet 9198 bytes
Jumbo Ethernet frame 10,240 bytes
Ingress protection IP20
Dying Gasp Yes

Electrical

Voltage (auto ranging) 110 to 220V AC in
Frequency 50 to 60 Hz
Current 0.29A to 0.48A
Power rating (maximum consumption) 0.09 kVA



C1000-48T-4X-L : Catalyst 1000 48 port GE, 4x10G SFP

Data sheet Switch Cisco C1000-48T-4X-L
