FortiAP U24JEV (FAP-U24JEV)

FortinNet FortiAP U24JEV (FAP-U24JEV): Wall Plate Universal AP - Single radio [can be configured as two] (802.11 a/b/g/n/ac, 2x2 MIMO 2.4GHz/5GHz or 1x1 SISO 2.4GHz and 1x1 SISO 5GHz), internal antennas, 4 x 10/100/1000 RJ45 port (1x 802.3at PoE PD, 1x 802.3af PoE PSE, 2x Non-PoE Ports), . Mounting bracked included.For power order: 802.3af PoE injector GPI-115 (limited features) or 802.3at PoE injector GPI-130 or AC adapter SP-FAPU24-PA.
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị mạng không dây FortiAP U24JEV

Hardware
Hardware Type Universal Wall Plate AP
Number of Radios 1 (can operate as 2)
Number of Antennas 2
Peak Antenna Gain 3 dBi for 2.4 GHz 4 dBi for 5 GHz
Frequency Bands (GHz) 2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850
Frequency of Radio 1 2.4 GHz b/g/n (2x2:2 stream) 20/40 MHz (64 QAM) 5 GHz a/n/ac (2x2:2 stream) 20/40/80 MHz (256 QAM) 2x (1x1:1) 2.4 GHz and 5 GHz
Maximum Data Rate 867 Mbps
Tx/Rx Streams 2x2 MIMO 2 spatial stream (1x1 when operating in 2.4 and 5 GHz dual concurrent mode)
Bluetooth Low Energy (BT/BLE) Radio Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power
Ethernet Ports 6 Ports, 1x GE 802.3at PoE (PD), 1x GE 802.3af PoE (PSE), 2x Non-PoE GE Ports, Pass-through in and Pass-through out
USB Port No
Serial Console Port No
Power over Ethernet (PoE) Yes
Simultaneous SSIDs 16 (14 if background scanning enabled)
EAP Type(s) EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST
User/Device Authentication WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist
Maximum Tx Power 20 dBm (100mW)
Physical Security Designed to attach to existing backbox
IEEE Specifications 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x, 802.3af, 802.11ac, 802.3at, 802.3az, 802.3ad
Wireless Mesh Capable No
FortiPresence Capable Yes
Modes of Operation WLC (8.4 and above), FortiGate, FortiCloud
SSID Types Supported Local-Bridge, Tunnel & Mesh (when managed by FortiGate)
FortiDeploy and FortiCloud Key Yes
Per Radio Client Capacity Up to 128
LED Off Mode Yes
Advanced 802.11 Features
802.11ac MU-MIMO Wave 2 No
Transmit Beam Forming (TxBF) Yes
Low-Density Parity Check (LDPC) Encoding Yes
Maximum Likelihood Demodulation (MLD) Yes
Maximum Ratio Combining (MRC) Yes
A-MPDU and A-MSDU Packet Aggregation Yes
MIMO Power Save Yes
Short Guard Interval Yes
WME Multimedia Extensions Yes
Wireless Monitoring Capabilities
Frequencies scanned 2.4 and 5 GHz
Background scan with client access on 2.4 and 5 GHz Yes (dependent on configuration)
Full-time scan as dedicated monitor Yes
Packet sniffer mode Yes
Spectrum analyzer Yes
Dimensions
Length x Width x Height 6.1 x 3.7 x 1.2 inches (155 x 95 x 31 mm)
Weight 9.1 oz (258 g)
Package (shipping) Weight 21.4 oz (606 g)
Mounting Options Wall Mount or Desk Stand
Included Accessories Mounting Kit
Environment
Power Supply Adapter input: 100–240V, 50/60Hz, 0.9A Maximum output: 12V DC, 3A
Power Consumption (Average / Maximum) Depends on PoE connected and USB power consumed



FAP-U24JEV: Wall Plate Universal AP - Single radio [can be configured as two] (802.11 a/b/g/n/ac, 2x2 MIMO 2.4GHz/5GHz or 1x1 SISO 2.4GHz and 1x1 SISO 5GHz), internal antennas, 4 x 10/100/1000 RJ45 port (1x 802.3at PoE PD, 1x 802.3af PoE PSE, 2x Non-PoE Ports), . Mounting bracked included.For power order: 802.3af PoE injector GPI-115 (limited features) or 802.3at PoE injector GPI-130 or AC adapter SP-FAPU24-PA.

FC-10-P024E-247-02-DD: 24x7 FortiCare Contract

Data sheet FortiAP U24JEV
