GrandStream GWN7605

GrandStream GWN7605 802.11ac Wave-2 2x2:2 Wi-Fi Access Point : ● 1.27Gbps aggregate wireless throughput and 2xGigabit wireline ports ● Dual-band 2x2:2 MU-MIMO with beamforming technology ● Self power adaptation upon auto detection of PoE/PoE+ ● Supports 100+ concurrent Wi-Fi client devices ● Up to 165 meter coverage range ● Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise-based software controller
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị phát sóng wifi Grandstream GWN7605

Model GWN7605
Wi-Fi Standards • IEEE 802.11a/b/g/n/ac (Wave-2)
Antennas • 2 dual band internal antennas
• 2.4GHz, gain 3dBi
• 5 GHz, gain 4dBi
Wi-Fi Data Rates • IEEE 802.11ac: 6.5 Mbps to 867 Mbps
• IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• IEEE 802.11n: 6.5Mbps to 300Mbps;
• IEEE 802.11b: 1, 2, 5.5, 11 Mbps
• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
 *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands  • 2.4 GHz Radio: 2412 – 2484 MHz
• 5 GHz Radio: 5180-5825 MHz
Channel Bandwidth  • 2.4G: 20 and 40 MHz
• 5G: 20,40 and 80 MHz
Wi-Fi and System Security • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
MIMO  • 2x2:2 2.4GHz (MIMO)
• 2x2:2 5GHz (MU-MIMO)
Coverage Range  • Up to 165 meters
 *coverage range can vary based on environment
Maximum TX Power • 2.4G:24dBm
• 5G:22dBm
 *Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity 2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40: -63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
SSIDs  • 16 SSIDs total, 8 per radio (2.4 Ghz and 5 Ghz)
Concurrent Clients  • 100+
Network Interfaces  • 2 x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports  • 1 x Reset Pinhole, 1 x Kensington lock
Mounting  • Indoor wall or ceiling mount, kits included
LEDs  • 3 x tri-color LED for device tracking and status indication
Network Protocols  • IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS  • 802.11e/WMM, VLAN, TOS
Network Management • Embedded controller can manage up to 50 local GWN APs
• GWN Cloud offers a free cloud management platform for unlimited GWN APs
• GWN Manager offers premise-based software controller for up to 3,000 GWN APs
Power and Green Energy Efficiency  • PoE 802.3af/ 802.3at; Maximum Power Consumption:10.16W
Environmental • Operation: 0°C to 40°C
• Storage: -10°C to 60°C
• Humidity: 10% to 90% Non-condensing
Physical  • Unit Dimension: 180.4mmx180.4mmx40.8mm; Unit Weight: 388.2g
• Entire Package Dimension: 228.5x220x79mm; Entire Package Weight: 719.3g
Package Content  • GWN7605 802.11ac Wireless AP, Mounting Kits, Quick Start Guide
Compliance  • FCC, CE, RCM, IC
