Juniper SRX340-SYS-JB

Firewall Juniper SRX340-SYS-JB : SRX340 Services Gateway includes hardware (16GbE, 4x MPIM slots, 4G RAM, 8G Flash, power supply, cable and RMK) and Junos Software Base (firewall, NAT, IPSec, routing, MPLS and switching)
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Thiết bị tường lửa Firewall Juniper SRX340-SYS-JB

Model SRX340-SYS-JB
Connectivity
Total onboard ports 16x1GbE
Onboard RJ-45 ports 8x1GbE
Onboard small form-factor pluggable (SFP) transceiver ports 8x1GbE
MACsec-capable ports 16x1GbE
Out-of-band (OOB) management ports 1x1GbE
Mini PIM (WAN) slots 4
Console (RJ-45 + miniUSB) 1
USB 3.0 ports (type A) 1
PoE+ ports 0
Memory and Storage
System memory (RAM) 4 GB
Storage 8 GB
SSD slots 1
Performance and Scale
Routing with packet mode (64 B packet size) in Kpps 550
Routing with packet mode (IMIX packet size) in Mbps 1600
Routing with packet mode (1,518 B packet size in Mbps 3000
Stateful firewall (64 B packet size) in Kpps 350
Stateful firewall (IMIX packet size) in Mbps 1100
Stateful firewall (1,518 B packet size) in Mbps 3000
IPsec VPN (IMIX packet size) in Mbps 200
IPsec VPN (1,400 B packet size) in Mbps 600
Application visibility and control in Mbps 1000
Recommended IPS in Mbps 400
Next-generation firewall in Mbps 200
Route table size (RIB/FIB) (IPv4 or IPv6) 1 million/600,00010
Maximum concurrent sessions (IPv4 or IPv6) 256000
Maximum security policies 2000
Connections per second 10000
NAT rules 2000
MAC table size 15000
IPsec VPN tunnels 1024
Number of remote access/SSL VPN (concurrent) users 150
GRE tunnels 512
Maximum number of security zones 64
Maximum number of virtual routers 64
Maximum number of VLANs 2000
AppID sessions 64000
IPS sessions 64000
URLF sessions 64000
Dimensions and Power
Form factor 1 U
Size (WxHxD) 17.36 x 1.72 x 14.57 in. (44.09 x 4.36 x 37.01 cm)
Weight (device and PSU) 10.80 lb (4.90 kg)
Redundant PSU No
Power supply AC (internal)
DC Input N/A
Maximum PoE power N/A
Average power consumption 122 W
Average heat dissipation 420 BTU/h
Maximum current consumption 1.496 A
Acoustic noise level 45.5 dBA
Airflow/cooling Front to back
Environmental, Compliance, and Safety Certification
Operational temperature 32° to 104° F (0° to 40° C)
Nonoperational temperature -4° to 158° F (-20° to 70° C)
Operating humidity 10% to 90% noncondensing
Nonoperating humidity 5% to 95% noncondensing
Meantime between failures (MTBF) 27 years
FCC classification Class A
RoHS compliance RoHS 2
FIPS 140-2 Level 2 (Junos 15.1X49-D60)
Common Criteria certification NDPP, VPNEP, FWEP, IPSEP (based on Junos 15.1X49-D60)

Interface Modules

SRX-MP-1T1E1-R 1 port T1E1, MPIM form factor supported on SRX320, SRX340, SRX345, SRX380, and SRX550M. ROHS complaint
SRX-MP-1VDSL2-R 1 port VDSL2 (backward compatible with ADSL / ADSL2+), MPIM form factor supported on SRX320, SRX340, SRX345, SRX380, and SRX550M. ROHS complaint
SRX-MP-LTE-AA 4G / LTE MPIM support 1, 3, 5, 7-8, 18-19, 21, 28, 38-41 LTE bands (for Asia and Australia). Supported on SRX320, SRX340, SRX345, SRX380, and SRX550M
SRX-MP-WLAN-WW  Wireless access point (Wi-Fi) MPIM for SRX320, SRX34x, SRX380, and SRX550M. Supported for worldwide regulatory bands
SRX-MP-ANT-EXT  Antenna extension cable for WLAN MPIM on SRX Series platforms

SRX340-SYS-JB : SRX340 Services Gateway includes hardware (16GbE, 4x MPIM slots, 4G RAM, 8G Flash, power supply, cable and RMK) and Junos Software Base (firewall, NAT, IPSec, routing, MPLS and switching)

Data sheet Juniper SRX300 Line Of Services Gateways For The Branch
