Module quang SFP Cisco

GLC-SX-MMD= 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM 1km; GLC-LH-SMD= 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM 10km; GLC-GE-100FX= 100BASE-FX SFP for GE SFP port on 3850, 3650, 2960X, 2960+, 2960L; GLC-TE= 1000BASE-T SFP transceiver module for copper wire 100m;

Giá bán : Liên hệ để có giá tốt
Tình trạng : Còn hàng

Thông số kỹ thuật
Tài liệu liên quan

Module Quang Cisco đầy đủ (Module SFP Cisco Full)

No	Part Number	Description	Max Distance
I	Cisco 100BASE Small Form-Factor Pluggable (SFP) Modules
1	GLC-GE-100FX=	100BASE-FX SFP for GE SFP port on 3850, 3650, 2960+, 2960X, 2960L	2 km
II	Cisco 1000BASE Small Form-Factor Pluggable (SFP) Modules
1	MGBT1	Gigabit Ethernet 1000 Base-T Mini-GBIC SFP Transceiver	100 m
2	MGBSX1	Gigabit Ethernet SX Mini-GBIC SFP Transceiver	500 m
3	MGBLH1	Gigabit Ethernet LH Mini-GBIC SFP Transceiver	40 km
4	GLC-TE=	1000BASE-T SFP transceiver module for Category 5 copper wire	100 m
5	GLC-SX-MMD=	1000BASE-SX SFP transceiver module, MMF, 850nm, DOM	1 km
6	GLC-LH-SMD=	1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM	10 km
7	GLC-BX-D=	1000BASE-BX SFP, 1490NM	10 km
8	GLC-BX-U=	1000BASE-BX SFP, 1310NM	10 km
9	GLC-EX-SMD=	1000BASE-EX SFP transceiver module, SMF, 1310nm, DOM	40 km
10	GLC-ZX-SMD=	1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM	70km
III	Cisco 10GBASE Small Form-Factor Pluggable Plus (SFP+) Modules
11	SFP-10G-SR-S=	10GBASE-SR SFP Module, Enterprise-Class	400 m
12	SFP-10G-SR=	10GBASE-SR SFP Module	400 m
13	SFP-10G-LRM=	10GBASE-LRM SFP Module	300 m
14	SFP-10G-LR-S=	10GBASE-LR SFP Module, Enterprise-Class	10 km
15	SFP-10G-LR=	10GBASE-LR SFP Module	10 km
16	SFP-10G-BXD-I=	SFP+ Bidirectional for 10km, downstream	10 km
17	SFP-10G-BXU-I=	SFP+ Bidirectional for 10km, upstream	10 km
18	SFP-10G-BX40D-I=	SFP+ Bidirectional for 40km, downstream	40 km
19	SFP-10G-BX40U-I=	SFP+ Bidirectional for 40km, upstream	40 km
20	SFP-10G-ER-S=	10GBASE-ER SFP Module, Enterprise-Class	40 km
21	SFP-10G-ER=	10GBASE-ER SFP Module	40 km
22	SFP-10G-ZR-S=	10GBASE-ZR SFP Module, Enterprise-Class	80 km
23	SFP-10G-ZR=	Cisco 10GBASE-ZR SFP10G Module for SMF	80 km
24	SFP-H10GB-CU1M=	10GBASE-CU SFP+ Cable 1 Meter	1 m
25	SFP-H10GB-CU1-5M=	10GBASE-CU SFP+ Cable 1.5 Meter	1,5 m
26	SFP-H10GB-CU2M=	10GBASE-CU SFP+ Cable 2 Meter	2 m
27	SFP-H10GB-CU2-5M=	10GBASE-CU SFP+ Cable 2.5 Meter	2,5 m
28	SFP-H10GB-CU3M=	10GBASE-CU SFP+ Cable 3 Meter	3 m
29	SFP-H10GB-CU5M=	10GBASE-CU SFP+ Cable 5 Meter	5 m
30	SFP-H10GB-ACU7M=	Active Twinax cable assembly, 7m	7 m
31	SFP-H10GB-ACU10M=	Active Twinax cable assembly, 10m	10 m
32	SFP-10G-AOC1M=	10GBASE Active Optical SFP+ Cable, 1M	1 m
33	SFP-10G-AOC2M=	10GBASE Active Optical SFP+ Cable, 2M	2 m
34	SFP-10G-AOC3M=	10GBASE Active Optical SFP+ Cable, 3M	3 m
35	SFP-10G-AOC5M=	10GBASE Active Optical SFP+ Cable, 5M	5 m
36	SFP-10G-AOC7M=	10GBASE Active Optical SFP+ Cable, 7M	7 m
37	SFP-10G-AOC10M=	10GBASE Active Optical SFP+ Cable, 10M	10 m
IV	Cisco 40GBASE Quad Small Form-Factor Pluggable (QSFP+) Modules
38	QSFP-40G-SR-BD=	QSFP40G BiDi Short-reach Transceiver	150 m
39	QSFP-40G-SR4-S=	40GBASE-SR4 QSFP Trnscvr Module, MPO Conn, Enterprise-Class	150 m
40	QSFP-40G-SR4=	40GBASE-SR4 QSFP Transceiver Module with MPO Connector	150 m
41	QSFP-40G-CSR4=	QSFP 4x10GBASE-SR Transceiver Module, MPO, 300M	400 m
42	WSP-Q40GLR4L-RF	QSFP 40G Ethernet - LR4 Lite, LC, 2KM REMANUFACTURED	2 km
43	QSFP-40G-LR4-S=	QSFP 40GBASE-LR4 Trnscvr Mod, LC, 10km, Enterprise-Class	10 km
44	QSFP-40G-LR4=	QSFP 40GBASE-LR4 OTN Transceiver, LC, 10KM	10 km
45	QSFP-40G-ER4=	QSFP 40GBASE-ER4 Transceiver Module, LC, 40KM	40 km
46	QSFP-H40G-CU1M=	40GBASE-CR4 Passive Copper Cable, 1m	1 m
47	QSFP-H40G-CU3M=	40GBASE-CR4 Passive Copper Cable, 3m	3 m
48	QSFP-H40G-CU5M=	40GBASE-CR4 Passive Copper Cable, 5m	5 m
49	QSFP-H40G-ACU7M=	40GBASE-CR4 Active Copper Cable, 7m	7 m
50	QSFP-H40G-ACU10M=	40GBASE-CR4 Active Copper Cable, 10m	10 m
51	QSFP-H40G-AOC1M=	40GBASE Active Optical Cable, 1m	1 m
52	QSFP-H40G-AOC2M=	40GBASE Active Optical Cable, 2m	2 m
53	QSFP-H40G-AOC3M=	40GBASE Active Optical Cable, 3m	3 m
54	QSFP-H40G-AOC5M=	40GBASE Active Optical Cable, 5m	5 m
55	QSFP-H40G-AOC7M=	40GBASE Active Optical Cable, 7m	7 m
56	QSFP-H40G-AOC10M=	40GBASE Active Optical Cable, 10m	10 m
57	QSFP-H40G-AOC15M=	40GBASE Active Optical Cable, 15m	15 m
58	QSFP-H40G-AOC20M=	40GBASE Active Optical Cable, 20m	20 m
59	QSFP-H40G-AOC25M=	40GBASE Active Optical Cable, 25m	25 m
60	QSFP-H40G-AOC30M=	40GBASE Active Optical Cable, 30m	30 m
V	Cisco 100GBASE Quad Small Form-Factor Pluggable (QSFP+) Modules
61	QSFP-100G-SR4-S=	100GBASE SR4 QSFP Transceiver, MPO, 100m over OM4 MMF	100 m
62	QSFP-40/100-SRBD=	100G and 40GBASE SR-BiDi QSFP Transceiver, LC, 100m OM4 MMF	100 m
63	QSFP-100G-PSM4-S=	100GBASE PSM4 QSFP Transceiver, MPO, 500m over SMF	500 m
64	QSFP-100G-SM-SR=	100GBASE CWDM4 Lite QSFP Transceiver, 2km over SMF, 10-60C	2 km
65	QSFP-100G-CWDM4-S=	100GBASE CWDM4 QSFP Transceiver, LC, 2km over SMF	2 km
66	QSFP-100G-LR4-S=	100GBASE LR4 QSFP Transceiver, LC, 10km over SMF	10 km
67	QSFP-100G-CU1M=	100GBASE-CR4 Passive Copper Cable, 1m	1 m
68	QSFP-100G-CU2M=	100GBASE-CR4 Passive Copper Cable, 2m	2 m
69	QSFP-100G-CU3M=	100GBASE-CR4 Passive Copper Cable, 3m	3 m
70	QSFP-100G-CU5M=	100GBASE-CR4 Passive Copper Cable, 5m	5 m
71	QSFP-100G-AOC1M=	100GBASE QSFP Active Optical Cable, 1m	1 m
72	QSFP-100G-AOC2M=	100GBASE QSFP Active Optical Cable, 2m	2 m
73	QSFP-100G-AOC3M=	100GBASE QSFP Active Optical Cable, 3m	3 m
74	QSFP-100G-AOC5M=	100GBASE QSFP Active Optical Cable, 5m	5 m
75	QSFP-100G-AOC7M=	100GBASE QSFP Active Optical Cable, 7m	7 m
76	QSFP-100G-AOC10M=	100GBASE QSFP Active Optical Cable, 10m	10 m
77	QSFP-100G-AOC15M=	100GBASE QSFP Active Optical Cable, 15m	15 m
78	QSFP-100G-AOC20M=	100GBASE QSFP Active Optical Cable, 20m	20 m
79	QSFP-100G-AOC25M=	100GBASE QSFP Active Optical Cable, 25m	25 m
80	QSFP-100G-AOC30M=	100GBASE QSFP Active Optical Cable, 30m	30 m

Kiểm tra tính tương thích với thiết bị (Compatible Modules SFP Cisco) - Xem tại đây

Công ty Thế Giới Mạng chúng tôi chuyên phân phối và cung cấp thiết bị mạng Cisco và Module Quang SFP Cisco đầy đủ các loại, Quý Khách có nhu cầu vui lòng liên hệ để được tư vấn và hỗ trợ giá tốt nhất. Mọi chi tiết xin liên hệ:
