Draytek VigorAP 962C : WiFi 6 AX3000, Mesh WiFi, LAN PoE+ 2.5Gbps
Bộ phát sóng WiFi Draytek VigorAP 962C mang lại nhiều lợi ích, khiến nó trở thành một lựa chọn tuyệt vời để nâng cao mạng của bạn:
Những tính năng này làm cho VigorAP 962C trở thành một lựa chọn mạnh mẽ và linh hoạt cho cả mạng doanh nghiệp và gia đình
Thông số kỹ thuật
Models | VigorAP 962C |
Interface | |
LAN Port | 1 x 2.5G/1G/100M/10M Ethernet, RJ-45 (PoE-PD Support) |
Power | 1 x DC Power Input |
Button | 1 x Factory Reset Button |
WLAN | |
WiFi 6 | ● |
2.4GHz WLAN | 802.11b/g/n/ax |
5GHz WLAN | 802.11a/n/ac wave 2/ax |
Antennas | 5x Internal PiFA DB |
2.4G Max. Link Rate (Mbps) | 600 |
5G Max. Link Rate (Mbps) | 2400 |
Max. Clients | 256 |
Operating Mode | AP, Mesh Root, Mesh Node, Range Extender |
Roaming | AP-Assisted, Pre-Authentication, 802.11r, 802.11v, 802.11k |
AirTime Fairness | ● |
Band Steering | ● |
OFDMA | ● |
Max. Number of SSID | 16 (8 per radio band) |
WDS | Repeater |
WMM | ● |
Security | |
Security Mode | OWE, WEP, WPA, WPA2/WPA, WPA2, WPA3/WPA2, WPA3 |
Authentication | Personal, Enterprise |
WPS | PIN, PBC |
MAC Address Filter (Max. entry number) | 256 |
Application | |
DHCP | DHCP Server, DHCP Client, DHCP Relay Agent |
Static IP | ● |
802.1q tag-based VLAN | ● |
Schedule | Wi-Fi Up/Down |
Management | |
Local Service | HTTP, HTTPS, Telnet |
Firmware Upgrade | HTTP, TFTP, TR-069 |
Config Backup/Restore | ● |
Syslog | ● |
SNMP | v1, v2c, v3 |
Stand-Alone Operation | ● |
Mesh | Node, Root |
Central AP Management (Number of manageable APs) | 20 |
VigorRouter Management (APM) | ● |
VigorACS Management | ● |
Physical
|
|
Environment | Indoor |
Mounting | Wall / Ceiling |
Power via | DC / PoE |
Power Input | 12V DC @ 1.5A |
Max. Power Consumption (watts) | 12 |
Dimension (mm) | 190 x 190 x 30 |
Weight (g) | 390 |
Operating Temperature | 0 to 40°C |
Storage Temperature | -20 to 60°C |
Operating Humidity (non-condensing) | 10 to 90% |
Liên hệ để có giá tốt
