Meraki MR28-HW

Bộ phát Wifi MR28-HW Meraki MR28 Cloud Managed 802.11ax AP

  • 1 × Gigabit Ethernet port
  • 802.3af PoE (37-57V) or 12V DC power adapter
  • 1 × 2.4 Ghz 802.11b/g/n/ax
  • 1 × 5 GHz 802.11a/n/ac/ax
  • 1.5 Gbit/sec max frame rate
  • License Options: Enterprise 1Yr, 3Yr, 5,Yr, 7Yr, 10Yr; Advanced 1Yr, 3Yr, 5Yr
  • Giá bán : Liên hệ để có giá tốt
  • Tình trạng : Còn hàng


Bộ phát không dây Meraki MR28 Wi-Fi 6 Indoor AP MR28-HW

Model MR28-HW
Usage Entry Level, Basic Coverage
Radio specification Dual-band (2.4 GHz, 5 GHz)
Spatial streams 2x2:2
Bluetooth Low Energy/IoT Radio
Aggregate frame rate 1.5 Gbps
Interface 1x Gigabit Ethernet
Power 802.3af PoE or DC power adapter
Management Cloud-managed with Meraki cloud
PoE 802.3af PoE compliant or DC power adapter
Performance features UL/DL-OFDMA, TWT support, BSS coloring
SU-MIMO, UL/DL MU-MIMO support
Maximal ratio combining (MRC) and beamforming
Priority voice, power save (802.11e/WMM)
Hardware-accelerated encryption
Band Steering
Dimensions 7.95 in x 4.88 in x 1.02 in (20.2 cm x 12.4 cm x 26cm)
Weight 9.6 oz (0.27 kg)
Tùy chọn License cho WiFi Meraki MR series
License Description
Meraki Enterprise License
LIC-ENT-1YR Cisco Meraki MR Enterprise License and Support, 1 Year
LIC-ENT-3YR Cisco Meraki MR Enterprise License and Support, 3 Years
LIC-ENT-5YR Cisco Meraki MR Enterprise License and Support, 5 Years
LIC-ENT-7YR Cisco Meraki MR Enterprise License and Support, 7 Years
LIC-ENT-10YR Cisco Meraki MR Enterprise License and Support, 10 Years
Meraki Advanced License
LIC-MR-ADV-1Y Cisco Meraki MR Advanced License and Support, 1 Year
LIC-MR-ADV-3Y Cisco Meraki MR Advanced License and Support, 3 Years
LIC-MR-ADV-5Y Cisco Meraki MR Advanced License and Support, 5 Years
Meraki Upgrade License
LIC-MR-UPGR-1Y Cisco Meraki MR ENT to ADV Upgrade License, 1 Year
LIC-MR-UPGR-3Y Cisco Meraki MR ENT to ADV Upgrade License, 3 Year
LIC-MR-UPGR-5Y Cisco Meraki MR ENT to ADV Upgrade License, 5 Years

MR28-HW : Meraki MR28 Cloud Managed 802.11ax AP

Data sheet Cloud-Managed Wireless Access Points MR Series

Thông số kỹ thuật:

  • Radios
    • 2.4 GHz 802.11b/g/n/ax client access radio
    • 2.4 GHz Bluetooth® Low Energy (BLE 5) radio with Beacon and BLE scanning support
    • 5 GHz 802.11a/n/ac/ax client access radio
    • Supported frequency bands (country-specific restrictions apply):
      • 2.412-2.484 GHz
      • 5.150-5.250 GHz (UNII-1)
      • 5.250-5.350 GHz (UNII-2)
      • 5.470-5.600, 5.660-5.725 GHz (UNII-2e)
      • 5.725-5.825 GHz (UNII-3)
  • Antenna
    • Internal Antenna (5.4 dBi gain at 2.4 GHz, 6 dBi gain at 5 GHz)
  • 802.11ax, 802.11ac Wave 2, and 802.11n Capabilities
    • UL/DL-OFDMA, UL-OFDMA, TWT support, BSS coloring
    • 2×2 multiple input, multiple output (MIMO) with 2 spatial streams
    • SU-MIMO, UL MU-MIMO and DL MU-MIMO support
    • Maximal ratio combining (MRC) & beamforming
    • 20 and 40 MHz channels (802.11n) 20, 40, and 80 MHz channels (802.11ac Wave 2)
    • Up to 1024 QAM on both 2.4 GHz & 5 GHz bands
    • Packet aggregation
  • Power
    • Power over Ethernet: 37-57 V (802.af compliant)
    • Power consumption: 15 W max (802.3af)
    • Power over Ethernet injector sold separately
  • Interfaces
    • 1x 10/100/1000 BASE-T Ethernet (RJ45)
  • Physical Security
    • Two security screw options (included) (10 mm long and 2.5 mm diameter and 4.7 mm head)
    • Concealed mount plate with anti-tamper cable bay
  • Environment
    • Operating temperature: 32 °F to 104 °F (0 °C to 40 °C)
    • Humidity: 5 to 95% non-condensing
    • Operating altitude: Up to 40,000 feet (12,192 meters)
  • Reliability
    • Mean Time Between Failure (MTBF): 257,215hrs at +25°C operating temperature
  • Physical Dimensions
    • 7.95” x 4.88” x 1.02” (202 mm x 124 mm x 25.8 mm), not including deskmount feet or mount plate
    • Weight: 9.6 oz (272 g)
  • Security
    • Integrated Layer 7 firewall with mobile device policy management
    • Flexible guest access with device isolation
    • VLAN tagging (802.1Q) and tunneling with IPSec VPN
    • PCI compliance reporting
    • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 - Personal, WPA3 - Enterprise, WPA3 - Enhanced Open (OWE)
    • EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
    • TKIP and AES encryption
    • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
    • Cisco ISE integration for guest access and BYOD Posturing
  • Quality of Service
    • Advanced Power Save (U-APSD)
    • WMM Access Categories with DSCP and 802.1p support
    • Layer 7 application traffic identification and shaping
  • Mobility
    • PMK, OKC, and 802.11r for fast Layer 2 roaming
    • Distributed or centralized Layer 3 roaming
  • Analytics
    • Embedded location analytics reporting and device tracking
    • Global L7 traffic analytics reporting per network, per device, & per application
  • LED Indicators
    • 1 power/booting/firmware upgrade status
  • Regulatory
    • RoHS
  • Warranty
    • Lifetime hardware warranty with advanced replacement included
  • Ordering Information
    • MR28-HW: Meraki MR28 Cloud Managed 802.11ax AP
    • MA-INJ-4 or MA-INJ-6
