Mô tả sản phẩm

Thiết bị chuyển mạch Switch Alcatel-Lucent OmniSwitch OS6360-P24

Model	OS6360-P24
Gigabit RJ-45 ports	24 PoE+
Combo Gigabit RJ-45/SFP ports	2
Fixed SFP/SFP+ uplink or VFL ports	2 x SFP+
Console port	1
USB/OoB management port	1
Primary power	Internal
Backup power	N/A
Fans	0
CPU	800MHz ARMv7
File system flash	1 GB
RAM	1 GB
Packet buffers	1.5MB
Performance aggregated
Max switching ASIC capacity	92 Gb/S
Switch capacity with all ports (full duplex + stacking)	92 Gb/s
Switch frame rate @ 64-byte packet	137 Mpps
2x10GE VFL capacity	40 Gb/s
System power consumption	- Idle : 16 W - 100% traffic all ports (max) : 28 W
System heat dissipation	95.5 (BTU/h)
Power consumption w/PoE	222 W
Heat dissipation w/PoE	758 (BTU/h)
Power supply efficiency (max load)	93,50%
Acoustics (dB) @27C*	0 db(A)
# of fans	0
MTBF (hours) @ 25C	1,447 k
Height	4.4 cm (1.73 in)
Width	4.4 cm (17.33 in)
Depth	22 cm (8.66 in)
Weight	3.2 kg (7 lbs)
Operating temperature	0°C to 45°C (32°F to 113°F)
Storage temperature	-40°C to 85°C E33 (-40°F to 185°F)
Humidity (operating)	5% to 95% non-condensing

Transceivers and cables

SFP-GIG-T	1000Base-T Gigabit Ethernet Transceiver (SFP MSA). SFP works at 1000 Mb/s speed and full-duplex mode.
SFP-GIG-SX	1000Base-SX Gigabit Ethernet optical transceiver (SFP MSA).
SFP-GIG-LX	1000Base-LX Gigabit Ethernet optical transceiver (SFP MSA).
SFP-GIG-LH40	1000Base-LH Gigabit Ethernet optical transceiver (SFP MSA). Typical reach of 40 km on 9/125 µm SMF
SFP-GIG-LH70	1000Base-LH Gigabit Ethernet optical transceiver (SFP MSA). Typical reach of 70 km on 9/125 µm SMF
OS6360-CBL-60CM	10 Gigabit direct attached uplink/stacking copper cable (60 cm, SFP+).
OS6360-CBL-C1M	10 Gigabit direct attached uplink/stacking copper cable (1 m, SFP+)
OS6360-CBL-C3M	10 Gigabit direct attached uplink/stacking copper cable (3 m, SFP+)
SFP-10G-SR	10 Gigabit optical transceiver (SFP+). Supports multimode fiber over 850 nm wavelength (nominal) with an LC connector. Typical reach of 300 m
SFP-10G-LR	10 Gigabit optical transceiver (SFP+). Supports single mode fiber with an LC connector. Typical reach of 10 Km.
SFP-10G-ER	10 Gigabit optical transceiver (SFP+). Supports single-mode fiber over 1550 nm wavelength (nominal) with an LC connector. Typical reach of 40 km
SFP-10G-BX-D	10 Gigabit optical transceiver (SFP+) with an LC type of interface. This bi-directional transceiver is designed for use over single mode fiber optic on a single strand link up to 10 km. Transmits 1270 nm and receives 1330 nm optical signal.
SFP-10G-BX-U	10 Gigabit optical transceiver (SFP+) with an LC type of interface. This bi-directional transceiver is designed for use over single mode fiber optic on a single strand link up to 10 km. Transmits 1330 nm and receives 1270 nm optical signal
